CUTMASTER 152
OPERATION
Manual 0-4987
4T-10
Type Torch: SL100 With Exposed Tip
Type Material: Aluminum
Type Plasma Gas: Air
Type Secondary Gas: Single Gas Torch
Thickness
Tip
Output
Amperage Speed (Per Minute)
Standoff
Plasma Gas Press
Flow (CFH)
Pierce
Pierce Height
Inches mm (Cat. No.) Volts(VDC) (Amps)
Inches
Meters
Inches mm
psi*
bar
Plasma Total** Delay (Sec) Inches mm
0.032 0.8 9-8208
110
40
440
11.18
0.187 4.8
65
4.5
55
170
0.00
0.2
5.1
0.051 1.3 9-8208
109
40
350
8.89
0.187 4.8
65
4.5
55
170
0.10
0.2
5.1
0.064 1.6 9-8208
112
40
250
6.35
0.187 4.8
65
4.5
55
170
0.10
0.2
5.1
0.079 2.0 9-8208
112
40
200
5.08
0.19 4.8
65
4.5
55
170
0.30
0.2
5.1
0.125 3.2 9-8208
118
40
100
2.54
0.19 4.8
65
4.5
55
170
0.40
0.2
5.1
0.188 4.8 9-8208
120
40
98
2.49
0.187 4.8
65
4.5
55
170
0.60
0.2
5.1
0.250 6.4 9-8208
123
40
50
1.27
0.187 4.8
65
4.5
55
170
1.00
0.2
5.1
0.375 9.5 9-8208
134
40
16
0.41
0.187 4.8
65
4.5
55
170
NR
NR
NR
Type Torch: SL100 With Exposed Tip
Type Material: Mild Steel
Type Plasma Gas: Air
Type Secondary Gas: Single Gas Torch
Thickness
Tip
Output
Amperage Speed (Per Minute)
Standoff
Plasma Gas Press
Flow (CFH)
Pierce
Pierce Height
Inches mm (Cat. No.) Volts(VDC)
(Amps)
Inches
Meters
Inches mm
psi*
bar
Plasma Total** Delay (Sec) Inches mm
0.060 1.5 9-8210
110
60
290
7.37
0.19 4.8
70
4.8
90
245
0.00
0.19 4.8
0.075 1.9 9-8210
120
60
285
7.24
0.19 4.8
70
4.8
90
245
0.10
0.19 4.8
0.120 3.0 9-8210
120
60
180
4.57
0.19 4.8
70
4.8
90
245
0.10
0.19 4.8
0.135 3.4 9-8210
119
60
170
4.32
0.19 4.8
70
4.8
90
245
0.10
0.19 4.8
0.188 4.8 9-8210
121
60
100
2.54
0.19 4.8
70
4.8
90
245
0.20
0.19 4.8
0.250 6.4 9-8210
119
60
80
2.03
0.19 4.8
70
4.8
90
245
0.30
0.19 4.8
0.375 9.5 9-8210
124
60
50
1.27
0.19 4.8
70
4.8
90
245
0.50
0.19 4.8
0.500 12.7 9-8210
126
60
26
0.66
0.19 4.8
70
4.8
90
245
0.75
0.19 4.8
0.625 15.9 9-8210
127
60
19
0.48
0.19 4.8
70
4.8
90
245
NR
NR
NR
0.750 19.1 9-8210
134
60
14
0.36
0.19 4.8
70
4.8
90
245
NR
NR
NR
1.000 25.4 9-8210
140
60
6
0.15
0.19 4.8
70
4.8
90
245
NR
NR
NR
Type Torch: SL100 With Exposed Tip
Type Material: Stainless Steel
Type Plasma Gas: Air
Type Secondary Gas: Single Gas Torch
Thickness
Tip
Output
Amperage Speed (Per Minute)
Standoff
Plasma Gas Press
Flow (CFH)
Pierce
Pierce Height
Inches mm (Cat. No.) Volts(VDC) (Amps)
Inches
Meters
Inches mm
psi*
bar
Plasma Total** Delay (Sec) Inches mm
0.06
1.5 9-8210
119
60
350
8.91
0.19 4.8
70
4.8
90
245
0.00
0.20 5.1
0.075 1.9 9-8210
116
60
300
7.64
0.19 4.8
70
4.8
90
245
0.10
0.20 5.1
0.120 3.0 9-8210
123
60
150
3.82
0.19 4.8
70
4.8
90
245
0.10
0.20 5.1
0.135 3.4 9-8210
118
60
125
3.18
0.19 4.8
70
4.8
90
245
0.10
0.20 5.1
0.188 4.8 9-8210
122
60
90
2.29
0.19 4.8
70
4.8
90
245
0.20
0.20 5.1
0.250 6.4 9-8210
120
60
65
1.65
0.19 4.8
70
4.8
90
245
0.30
0.20 5.1
0.375 9.5 9-8210
130
60
30
0.76
0.19 4.8
70
4.8
90
245
0.50
0.20 5.1
0.500 12.7 9-8210
132
60
21
0.53
0.19 4.8
70
4.8
90
245
0.75
0.20 5.1
0.625 15.9 9-8210
130
60
15
0.38
0.19 4.8
70
4.8
90
245
NR
NR
NR
0.750 19.1 9-8210
142
60
12
0.31
0.25 6.4
70
4.8
90
245
NR
NR
NR
