INTRODUCTION & DESCRIPTION 2-2 Manual 0-2568
2.03 Specifications & Design
Features
The following apply to the Master Power Supply only:
1. Controls
ON/OFF Switch, Output Current Control, RUN/
SET/PURGE Switch, Secondary Gas Regulator,
Plasma Gas Regulator, Secondary Mode Switch, Sec-
ondary Water Flowmeter/Regulator, Optional Arc
Hour/Counter Meters
2. Control Indicators
LED Indicators:
AC , TEMP, GAS, DC, PILOT, COOLANT PRES, and
COOLANT COND
Gauges:
Secondary, Plasma, and Coolant Pressure Gauges
3. Input Power
V o lt a g e F re q u e n cy P h a se A m p e ra g e
2 0 0 5 0 o r 6 0 H z 3 9 8
2 2 0 5 0 o r 6 0 H z 3 8 9
2 3 0 5 0 o r 6 0 H z 3 8 5
3 8 0 5 0 o r 6 0 H z 3 5 1
4 1 5 5 0 o r 6 0 H z 3 4 7
4 6 0 5 0 o r 6 0 H z 3 4 2
5 0 0 5 0 o r 6 0 H z 3 4 0
5 7 5 5 0 o r 6 0 H z 3 3 4
NOTE
Refer to Appendix 1 for recommended input wir-
ing size, current ratings, and circuit protection re-
quirements.
Amps depends on input voltage (Refer to Appendix
1).
4. Output Power
Master Power Supply:
Continuously adjustable by potentiometer from 50
to 150 amps
With Slave Power Supply:
Continuously adjustable by potentiometer from
100 to 300 amps
5. Duty Cycle (see NOTE)
NOTE
The duty cycle will be reduced if the primary in-
put voltage (AC) is low or the DC voltage is higher
than shown in the chart.
Ambient
Temperature
104° F (40° C)
Duty Cycle 100%
Current 150 Amps
DC Voltage 140 vdc
Power Supply Duty Cycle
6. Pilot Modes
Auto-Restart, Pre-Flow Delay, "Recycle Required"
7. CNC Signals
Enable, Start/Stop, OK-To-Move, Pilot Sensing Re-
lay (PSR), Full CNC Available with Remote
8. Coolant Pressure
Internal Service-adjustable
130 psi (8.8 bar) at zero flow
120 - 125 psi (8.2 - 8.5 bar) at 0.6 gpm (2.6 lpm)
9. Coolant Flow Rate
0.5 gpm (2.2 lpm) with 150 feet of total torch and torch
leads at 70°F (21°C)
NOTE
The flow rate varies with lead length, torch con-
figuration, ambient temperature, amperage level,
etc.
10. Cooling Capacity
4,000 to 10,000 BTU
NOTE
Maximum value based on “free flow” condition.
11. Coolant Reservoir Capacity
2 gallons
Capable of handling a total of 150 feet of torch lead
length
