EVOLVE 55E PUMP OPERATION / MAINTENANCE MANUAL PAGE 3
1
INSTALLATION
1.1 UNPACKING
After unpacking, the pump should be checked for any damage that may have occurred
during shipment. Damage should be reported to the carrier immediately.
Although extensive efforts are made to deliver pumps to our customers completely dry, new
pumps may contain residual moisture from their final DI water test.
The following items should be included within the shipping container:
Qty Item Description
1 Pump Evolve 55E Pump
1 ME55E Operation/Maintenance Manual
1.2 UTILITIES / CONNECTION
It is recommended that the pump be positioned within 15

from level to maintain self-priming
ability and pumping efficiency. Allow sufficient room for tubing connectors. The pump
mounts on a quick-change base for easy installation.
The pump has dual exhaust locations on the backside of the base. The exhaust locations
require 1/2” (12mm) minimum clearance behind the control base. Care should be taken to
elevate the pump whenever possible to help prevent flooding when the pump is located in a
wet bench plenum. For remote exhaust connection, see Section 1.4.
Air Inlet: 1/4” FNPT (3/8” Dia. [8mm] supply tube minimum).
Air Supply: 20-100 psig (.14 - .69 MPa) clean dry air or nitrogen (see Performance
Charts, Section 3.1).
Fluid Ports: Inlet/Outlet fluid fittings and surge suppressor require torquing during pump
installation. See Section 2 for connection diagram and torque values.
