EVOLVE 55E PUMP OPERATION / MAINTENANCE MANUAL PAGE 11
Figure 3-1: Pump Performance Curves with Air Consumption
NOTE: Test information is based on specific conditions and limited sampling. Use for general
reference only.
2 SCFM 5 SCFM 10 SCFM
15 SCFM
20 SCFM
25 SCFM
0 LPM 10 LPM 20 LPM 30 LPM 40 LPM 50 LPM 60 LPM
0.00 MPa
0.10 MPa
0.20 MPa
0.30 MPa
0.40 MPa
0.50 MPa
0.60 MPa
0.70 MPa
0 PSI
10 PSI
20 PSI
30 PSI
40 PSI
50 PSI
60 PSI
70 PSI
80 PSI
90 PSI
100 PSI
0 GPM 2 GPM 4 GPM 6 GPM 8 GPM 10 GPM 12 GPM 14 GPM 16 GPM
D
isc
h
ar
ge
Pr
e
ssur
e
Flow
Evolve 55 Pump Performance
