EVOLVE 55E PUMP OPERATION / MAINTENANCE MANUAL
PAGE 17
4.5 PARTS LIST
ILL NO
PART NO
QTY
DESCRIPTION
PM YEAR #
MATERIAL
1
BK005
2
Union Nut
GFPP
1
AK003-01
2
PVDF Union Nut (optional
– not shown)
PVDF
2
BK026
2
Top Pilot Port Plug
PP
3
BK027
2
Exhaust Port Plug
PP
4
W0116
2
Exhaust Port Gasket
PTFE
5
AM035
2
Leak Port Plug
PP
6
AM037
2
Leak Port Gasket
PTFE
7
AM020
2
Top Pilot Port Gasket
PTFE
8
AK097
2
PTFE Slip Ring
PTFE
9
BK025
2
Bottom Pilot Port Plug
PP
10
AK120
2
Bottom Pilot Port Gasket
PTFE
11
BK004
2
Pump Head
PP
12
BK019
4
Diaphragm
2
PTFE
13
W0151
2
Fiber Optic Target
2
PTFE
14
BK009
16
Polypropylene Pin
PP
15
1700B0041
2
Push Plate
PTFE
16
AK004
1
Shaft
2
PFA
17
98003079
2
Shaft Seal
2
PTFE
18
BK001
1
Pump Body
PTFE
19
AM084
1
Damper Port Gasket
PTFE
20
AM075
1
Damper Port Plug
PTFE
21
AK026
2
Discharge Check Cage
PTFE
22
98001415
4
Check Ball
2
PTFE
23
98002334
4
O-ring
2
PTFE
24
AK068
2
Suction Check Cage
PTFE
25
AK066
2
Suction Check Seat
PTFE
26
AK153
2
Check Bore Gasket
2
PTFE
27
AK149
2
Check Bore Plug
PTFE
28
98003047
2
Quick Exhaust Seal
1 & 2
Viton
29
1900B0016
2
Quick Exhaust Port
1 & 2
UHMW
30
AK205
2
Muffler Assembly
1 & 2
PP
31
BK028
1
External Control Base
PP
32
98003080
1
1/4” NPT Plug
PP
33
AK088
1
Base Attachment Plate
PP
34
AK108
1
Lever
PP
35
98003071
1
Lever Attachment Screw
PP
36
98003260
4
Jaco Fitting
PP
37
AK182
4
Transfer Tube
PFA
4.6 CLEAN-UP
To help remove potentially dangerous chemicals prior to service or shipment, the pump
should be flushed with DI water or disassembled and thoroughly cleaned. Allow DI water to
flush through the inlet and out the outlet to prevent pressure build up.
CAUTION: When handling pump, wear appropriate personal protection gear,
including safety glasses.
