EVOLVE 55E PUMP OPERATION / MAINTENANCE MANUAL PAGE 15
4.2 RECOMMENDED SPARE PARTS
KRE55E-00-A Spares Rebuild Kit, which includes:
Part No Qty Description
KME55E-00-A 1 Maintenance Kit
Includes: (2)
(2)
(2) 98003047
1900B0016
AK205
Quick Exhaust Seal
Quick Exhaust Port
Muffler Assembly
KDE55E-00-A 1 Diaphragm Kit
Includes: (4)
(2) BK019
W0151
Diaphragm
Fiber Optic Target
98001415 4 PTFE Check Ball
98002334 4 PTFE O-ring
98003079 2 Shaft Seal
AK004 1 Shaft
AK153 2 Check Cap Seal
AM084 1 Damper Port Seal
W0116 2 Exhaust Port Gasket
AM020 2 Top Pilot Port Gasket
AK120 2 Bottom Pilot Port Gasket
AM037 2 Leak Port Gasket
BK009 16 Diaphragm Retention Pin, PP
4.3 TOOLS
The following tool kit is recommended as standard service equipment.
KTE55-00-A Tool Kit, which includes:
Part No Qty Description
98003108 1 Torque Wrench, 30-150 ft.-lbs ., 1/2” Drive Handle
98003150 1 Tool Case
98003305 1 Drive Handle
98003306 1 Wrench, Adj. , 15/16”
T0126 1 Tool, Shaft Insert
T0132 1 Rebuild Fixture
T0146 1 Tool, Pin, 3/4x1/4 Drive
T0147 1 Tool, Pin, 1x1/4 Drive
T0148 1 Tool, Pin, 1/2x1/4 Drive
T0149 1 Tool, Pin, Optic Cap, 3/4
T0174 1 Evolve 55 Torque Tool
T0175 1 Diaphragm Pin Tool
NOTE: If the optional AK003-01 (PVDF Union Nut) is chosen, tool T0129 is recommended
for standard service equipment disassembly.
