1 of 16 © 2005 D 704 - 04/05
D 704
04/05 Mixing Station 704
- Data Brochure
WARNING SYMBOL: THIS SYMBOL INDICATES THE PRESENCE OF HAZARDS WHICH
CAN CAUSE SEVERE PERSONAL INJURY, SUBSTANTIAL PROPERTY DAMAGE OR
EVEN DEATH IF IGNORED.
The Mixing Station 704 represents a breakthrough in the design, control and installation of radiant systems. The patent pending design
combines a variable speed injection mixing control (RMC), injection circulator, system circulator, and air elimination into a single unit.
Extremely versatile, the Mixing Station 704 can be set up to operate as an outdoor reset control, a setpoint control or a delta T limiting
control.
General
Mixing
Station 70
4
Table of Contents
TYPICAL PIPING ------------------------------------------------- 2
GETTING READY ------------------------------------------------ 3
APPLICATION ---------------------------------------------------- 3
DESIGN PROCEDURE ----------------------------------------- 3
INSTALLATION OF MIXING STATION 704 --------------- 4
OUTDOOR RESET MODE ------------------------------------ 5
OUTDOOR RESET SETTINGS ------------------------------ 5
SETPOINT AND DELTA T MODE --------------------------- 6
SETPOINT AND DELTA T SETTINGS --------------------- 7
BOILER OPERATION MODE --------------------------------- 7 SET UP OF RADIANT MIXING CONTROL --------------- 8
DISPLAY OPERATION ---------------------------------------- 11
TROUBLE SHOOTING ---------------------------------------- 13
ERROR MESSAGES ------------------------------------------- 14
REPLACING CARTRIDGE ASSEMBLY ----------------- 14
REPLACING THE CHECK VALVE ------------------------ 15
TECHNICAL DATA ---------------------------------------------- 15
CLEANING -------------------------------------------------------- 16
LIMITED WARRANTY STATEMENT ----------------------- 16
MIXING STATION 704 (RMB)
RADIANT MIXING CONTROL (RMC)
