19 of 20 © 2011 D 527 - 12/11
Job Record
Item Setting
Set Room Heat
Set Room Heat
Set Room Heat Away
Backlight
Units
Max Set Room Heat
Max Set Room Heat
Min Set Room Heat
Item Setting
Schedule Member
Heat Supply Pump
Heat Supply Pump Delay
Heat Cycles Per Hour
Air Group
tekmarNet ® Address
Floor Cooling
Jobsite Location ________________________________________________
Thermostat Location _____________________________________________
Technical Data
tekmarNet ® 2 Thermostat 527; One Stage Heat
Packaged weight 0.8 lb. (380 g)
Enclosure White PVC plastic, NEMA Type 1
Dimensions 2-7/8” H x 2-7/8” W x 13/16” D (73 x 73 x 21 mm)
Approvals CSA C US, meets Class B: ICES and FCC Part 15
Ambient conditions Indoor use only, 32 to 122°F (0 to 50°C).
RH max 80% up to 88°F (31°C) decreasing linearly to 50%
RH at 104°F (40°C)
Altitude 0 - 6560 feet (2000 m), Installation Category II,
Pollution Category 2
Power supply Provided by tekmarNet ® 2 Control, 1.3 VA
