User interface – tekmar 519 Thermostat Installation User Manual
Page 11
© 2013
519_D - 03/13
11 of 16
A Watts Water Technologies Company
HEAT ON
Heat is turned on.
MODE OFF
The heating system is off.
WARNING SYMBOL
Indicates an error is present.
MIN
The floor is at or below the
floor minimum temperature.
MAX
The floor has reached the
floor maximum temperature.
Home Screen
Symbols Description
User Interface
