11 of 16 © 2012 D 510 - 02/12
View Menu
ROOM TARGET
The current desired air temperature for the space. This item is
only available in the Installer access level.
(Must have an active air sensor.)
ROOM
The current air temperature for the space.
(Must have at least one active air sensor. This is the average of
all active air sensors.).
OUTDOOR
The current temperature at the outdoor sensor.
(Sens 2 must be set to Out.)
SLAB
The current slab temperature.
(Must have an active slab sensor. If two slab sensors are present,
this is the average temperature.)
The MIN Setpoint is displayed when running on Min.
REMOTE
The current temperature at the remote sensor.
(Sens 1 must be set to Rem.)
Adjust Menu (1 of 3)
MODE
Current mode of operation of the thermostat.
OFF, HEAT
ROOM HEAT (No Schedule)
Desired temperature for heating.
(Must have an active air sensor and be set to Heat.)
35 to 100°F (1.5 to 38.0°C)
SLAB MINIMUM (No Schedule)
Minimum slab temperature.
(Must have an active slab sensor.)
OFF, 34 to 122°F (OFF, 1.0 to 50.0°C)
