PIX 250i User Guide
75
Specifications
Audio Recording
Record/Playback • 16 channels record/playback, simultaneous with video
• Simultaneous Analog, HDMI or SDI, AES/EBU, selectable per channel
Analog Audio
Inputs • 2 Balanced, line-level inputs on XLR.
Outputs • 2 Balanced, line-level outputs on XLR
Frequency Response 10Hz-20kHz, +/- 0.5dB re 1kHz
THD + Noise 0.004% max (1kHz, 22Hz-22kHz)
Input and Output Topology Fully electronically balanced, RF, ESD, short, and overload protected;
pin-2 hot, pin-3 cold
Line Output Clipping Level +18dBu
Front Panel Headphone 1/4” with gain control
Line Input Clipping Level +26dBu
Input Impedance 10k
Digital Audio
Sample Rate / Bit Depth • 48 kHz
• 24-bit
AES3 • 8 channels in and out via DB-25, 110 ohm, 2 V p-p.
• Accepts 32k, 44.1k, 48k, 96k, 192k sample rates. with SRC at input.
HDMI • 8 channels embedded HDMI input
• 8 channels embedded HDMI output.
• Accepts 32k, 44.1k, 48k, 96k, 192k sample rates.
SDI • 16 channels embedded SDI input
• 16 channels embedded SDI output
• 48k sample rate, with sample rate conversion
File Storage
Disk Format exFAT
PIX-CADDY 2 mounted drives Two, front-mounted Sound Devices approved 2.5-inch drives
See Sound Devices’ website for a list of approved media: www.sounddevices.com/approved
Timecode and Sync
Modes Supported Freerun, 24 Hour run, Record run, External (LTC or SDI/HDMI)
Frame Rates 23.976, 24, 25, 29.97DF, 29.97ND, 30DF, 30ND
Accuracy • +/- 0.2ppm (½ frame per 24hrs) accuracy
• Holds accurate timecode for 4 hours after power is removed
