Sound Devices PIX 250i - Manual (Page 65)

PIX 250i User Guide
59
Se
tup Manag
ement & F
ir
m
w
ar
e U
pg
rades
Setup Management and Firmware Upgrades
Saving and Loading Setup Files
To save all of the current settings to a setup file, select the Setup Menu option
[Quick Setup - Save Settings to Drive 1]. Use the on-screen keyboard (or attached USB key-
board) to enter a name for the setup file. This will save all of the current settings to an XML
file at root of Drive 1. To load a previously saved setup file, select the Setup Menu option
[Quick Setup - Load Settings from Drive 1]. The setup XML file will have to be copied to the root of
Drive 1 prior to attempting to load it.
For a complete list of available Setup Menu options, see Setup Menu Options .
Formatting a storage device will also remove any setup files that are on the drive. Setup files can be stored
on a computer and copied back to the root of a PIX 250i drive to be loaded on the PIX 250i.
Custom Default Settings and Setup Menu Option Visibility
The Setup Menu option [Quick Setup - Load Factory Settings] loads a setup that is saved internally
to the PIX when it leaves the factory. It is possible to alter this “factory” setup, so that the Setup
Menu option [Quick Setup - Load Factory Settings] will load a custom default.
It is also possible to hide specific Setup Menu parameters and options. This is useful for Setup Menu
options that are not commonly used in a particular workflow, or to simplify use when lending the
unit to another user.
To customize defaults and Setup Menu option visibility:
1. Attach a USB keyboard to the PIX 250i’s USB keyboard port.
2. Press MENU to enter the Setup Menu.
3. Press Ctrl + Alt + F10 on the keyboard. If this is the first time this action has been performed
since powering the PIX 250i up, a password dialog will appear. Enter the password (the de-
fault password is “default”).
4. After the correct password has been entered, the Settings Customization Menu will appear.
Select Edit Menu & Default Values.
