Figure 4. In this 5.1-channel
system, two pairs of EMBRACE
surrounds are shown placed to
the sides of the listening area.
Figure 5. As an alternative
5.1-channel system, one pair of
EMBRACE surrounds can be
placed on the rear wall. The
other pair can be placed on side
walls or on the ceiling using an
optional ceiling-mount version,
available from your Revel dealer.
EMBRACE
Owner’s Manual
7
EMBRACE
Left
EMBRACE
Right
Screen Sub LF
Sub
Cntr
RF
Screen Sub
EMBRACE
Right
EMBRACE
Left
Optional
Ceiling Mounting
LF
Sub
Cntr
RF
EMBRACE
Left
EMBRACE
Right
