Revel Embrace User Manual
Page 11
Figure 9. In a Dual Drive™
7.1-channel system, a pair of
EMBRACE surrounds are shown
placed to cover the entire listen-
ing area (from the front to rear
row) with an emphasis on the
center of the seating area.
7.1-CHANNEL DUAL DRIVE™ PLACEMENT
This configuration utilizes the multi-channel controller’s ability to
electronically alter the radiation characteristics of the EMBRACE
surrounds. One result is greater flexibility of placement, since the
main listening axis can be shifted electronically, as shown in
Figure 9.
The EMBRACE surrounds should be placed to the sides of the
listeners, or optionally on the ceiling using the ceiling-mount version
of the EMBRACE. Consult your Revel dealer for more information.
EMBRACE
Owner’s Manual
11
Sub
Sub LF
RF
Screen
Cntr
or
or
EMBRACE
Left
EMBRACE
Right
