Figure 14. Routing and
connecting the speaker wire.
Figure 15. Mounting an
EMBRACE on a ceiling.
6. At each site, route the speaker wire through the cutout and,
using correct polarity, attach the ends to the terminals on the
rear of the EMBRACE, as shown in Figure 14. Also refer to
Speaker Connections starting on page 16.
8. Slide each cabinet onto the brackets while securely latching
shoulder screws within the retaining clips, as shown in Figure 15.
Remove the tape and template after mounting each EMBRACE.
EMBRACE
Owner’s Manual
15
High Frequenc
y
Le vel (dB)
Rear W all Pr oximity
0 -1 +1
Near Rear Wall
Normal
Fr ont
Remote Dipole /B i
Chats wo rth Calif ornia Made in U .S.A.
wallboard
(on ceiling)
rafter
rafter
EMBRACE Left
(rear view)
cutout
speaker wire
OUTER
BRACKET
(installed
in rafter)
SHOULDER SCREW
(in rafter)
High Frequenc
y
Le vel (dB)
Rear W all Pr oximity
0 -1 +1
Near Rear Wall
Normal
Fr ont
Remote Dipole /B i
Chats wo rth Calif ornia Made in U .S.A.
INNER BRACKET
On EMBRACE
OUTER BRACKET
On Ceiling
SHOULDER SCREW
On Ceiling (slides into CLIP)
RETAINING CLIP
And SPRING
On EMBRACE
EMBRACE Left
(rear view)
wallboard
(on ceiling)
rafter
rafter
