9
Image Yoke Mount
The Yoke has a ½” hole to accept industry standard
mounting hardware.
The Image 85 Yoke Mount can hang from a grid
by a junior pipe hanger using a Yoke Junior Pin
(MTP-I80), sold separately.
The Image 45 Yoke Mount can also hang from a
grid by a junior pipe hanger using a Yoke Junior Pin
(MTP-I80) or hang from a baby pipe hanger using a
Yoke Baby Receiver (MTP-I40) also sold separately.
The MTP-I80 includes a long bolt for the Image 85
Yoke Fixture and a short bolt for the Image 45 Yoke
Fixture.
Note: Because of weight capacity, the MTP-I40 can
only be used on the Image 45 Yoke Fixture.
The Image 85 and 45 Pole-Op Mount fixtures
include a yoke with an attached junior pin.
They can be hung from a grid with a junior pipe
hanger.
Junior pin attached to Pole-Op Yoke
Image Pole-Op Mount
