18
KAS-I80-1 KAS-I80-2 KAS-I80-4
Cases
Part Description Dimensions Weight Holds
Number (Empty)
KAS-I40-1 Image 45 Ship Case (1) 56.5 x 9 x 23.5” 27lb / 12.2kg Image 45 (1)
(143.5 x 23 x 59.5cm)
KAS-I80-1 Image 85 Ship Case (1) 56.5 x 8 x 35” 29lb / 13.1kg Image 85 (1)
(143.5 x 20.5 x 89cm)
KAS-I80-2 Image 85 Ship Case (2) 56.5 x 16 x 35” 103lb / 46.4kg Image 85 (2)
(143.5 x 40.5 x 89cm)
KAS-I80-4 Image 85 Ship Case (4) 33 x 35.5 x 64” 222lb / 100kg Image 85 (4)
(84 x 90 x 162.5cm)
KAS-48 4ft Lamp Ship Case 52.5 x 10.5 x 11” 15.5lb / 7kg 4ft Lamps (20)
(133.5 x 26.5 x 28cm)
INS-L4 4-Lamp Foam Pad 24 x 9 x 1” N/A Fits KAS-48
(61 x 23 x 2.5cm)
True Match Lamps
488-K29-S 4ft Kino 800ma KF29
488-K32-S 4ft Kino 800ma KF32
488-K55-S 4ft Kino 800ma KF55
488-K10-S 4ft Kino 800ma 420 Blue
488-K5-S 4ft Kino 800ma 525 Green
Note: Kino Flo recommends
Safety-Coated 420nm Blue for Bluescreen
and 525nm Green for Greenscreen.
®
