HCO ScoutGuard SG560C AppendixⅡ: Technical Specifications
Page 22
AppendixⅡ: Technical Specifications
Image Sensor
5MP Color CMOS,
8MP interpolation
Lens
F/NO=3.1mm
FOV(Field of View)=52°
Illumination Up to15M/49F
Detection Range Up to 22M/73F
Display Screen 2.0” TFT
Memory Card Up to 32GB
Picture Resolution
8MP = 3328 ×2496
5MP = 2560×1920
Video Resolution
640×480 (16fps)
320×240 (20fps)
PIR Sensor Multi Zone
Trigger Time 1.2s
Weight * 0.24 kg
Operation/Storage
Tem.
-20 - +60°C / -30 - +70°C
Interval 1s – 60 min.
Photo Burst 1–3
Video Length 1–60s
Power supply
8AA can take >500 10s video clips
with LED lights;
Stand-by Current < 0.3 mA (<7mAh/Day)
Low Battery Alert LED Indicator
Display Screen LCD display
Mounting Rope/Belt/Python lock
Dimensions** 140x 80x 50 mm
Operation Humidity 5% - 90%
Security authentication FCC, CE, RoHS
*without battery
