Delta-V 480 65mm 4800Kv EDF System Instructions
Thank you for purchasing the E-flite Delta-V 480 65mm 4800Kv EDF System (EFLDF480). This electric ducted fan
unit includes the installed BL480 4800Kv Ducted Fan outrunner motor and is an ideal choice for ducted fan airplanes
requiring 65mm diameter fan units. This system is the recommended high current 3S choice for E-flite’s F-16 400 DF.
The included BL480 Ducted Fan Brushless Motor, 4800Kv (EFLM1555DF) is purpose-built for this Delta-V 480 65mm
EDF and together will provide great power 3S performance.
Delta-V 480 65mm EDF System Features:
• Includes 65mm Fan Unit with installed BL480 Ducted Fan outrunner motor
• Ideal high current 3S option for the E-flite F-16 DF
• High-performance, efficient design EDF
• Injection molded, fiberglass-filled nylon
• Factory-balanced 65mm 6-blade rotor design
• BL480 4800Kv DF Motor is ideal for up to 650 input watts
• Designed for high current 3S Li-Po batteries capable of up to 60A
BL480 Ducted Fan Motor Specifications
Mounting Diameter: 20mm (.70 in)
Overall Diameter: 28mm (1.10 in)
Case Length: 53.2mm (2.10 in)
Motor Weight: 82g (2.9 oz)
Shaft Diameter: 3mm (.12 in)
Kv: 4800 (rpms per volt)
Io: 3.1A @ 10V (no load current)
Ri: .023 ohms (resistance)
Continuous Current: 45A*
Max Burst Current: 58A*
Cells: 3S Li-Po
Brushless ESC: 60A
Delta-V 480 65mm EDF Unit Specifications
Rotor Diameter: 65mm (2.5 in)
Shroud Outer Diameter: 68mm (2.7 in)
Shroud Length: 42mm (1.65 in)
Weight: 30g (1.05 oz)
Overall Weight: 112g (3.95 oz) (motor and EDF unit)
Performance Data (Measured Using BL480 4800Kv Motor)
Static Thrust: 1.6 lbs on 3S (11.1V)
RPM: 45,000 on 3S (11.1V)
Watts: 565 on 3S (11.1V)
Current: 56A on 3S (11.1V)
* Maximum Operating Temperature: 220 degrees Fahrenheit
* Adequate cooling is required for all motor operation at maximum current levels.
* Maximum Burst Current duration is 15 seconds. Adequate time between maximum burst intervals is required for
proper cooling and to avoid overheating the motor.
* Maximum Burst Current rating is for full high power and limited motor run flights. Lack of proper throttle
management result in damage to the motor since excessive use of burst current may overheat the motor.
Examples of Airplane Setups:
E-flite F-16 400 DF ARF
Comments – Expect blistering speed and virtually unlimited vertical performance.
Weight w/Battery: 26.6 oz (754g)
Battery: 2600mAh 3-Cell 11.1V Pro Lite V2 (THP26003SPL2)
ESC: 60A Pro SB Brushless (EFLA1060)
