Power Station 250W (EFLC4010)
Power Station 250W (EFLC4010) Features:
•
Universal AC input voltage range and detachable AC power cord
•
Short-circuit
, over current and over temperature protection circuitry
•
Chassis mount, rocker style, AC power switch
•
Power ON indicator light (Red LED)
•
Color coded, banana jack, power output terminals (Red = Positive, Black = Common)
Specifications:
•
Input Voltage: 100-240VAC (50/60Hz)
•
Output Voltage: 15VDC +/- 0.25VDC
•
Output Current: 16.5A/250W
•
Operating temperature: 0
˚ to 140˚ F (
0°C to +60°C)
Meaning of Special Language:
The following terms are used throughout the product literature to indicate various levels of potential harm when operating this
power supply:
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no possibility of
injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility of
serious injury.
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious
injury OR create a high probability of superficial injury.
NOTICE: This is a sophisticated hobby product and NOT a toy. It must be operated with caution and common sense and requires
some basic mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage to
the Product or other property. This Product is not intended for use by children without direct adult supervision. This Product manual
contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in this
manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or injury.
Operating Instructions
1. Ensure the power switch is set to OFF—the side of the rocker switch marked with a circle “ O ” should be pushed in.
2. Attach the banana plugs of your charger’s DC power input cable to the power supply’s banana plug jacks. Insert the positive (+)
cable into the Red (+) jack and the common or negative (-) cable into the Black (-) jack.
3. Insert the AC power cord in the charger and make sure it is fully seated. Plug the other end of the AC power cord into an
appropriate power socket.
4. Turn the power supply ON by pressing the side of the rocker switch marked with a vertical line “ l ”. The power indicator LED
should glow red. The internal cooling fan will begin to rotate and the charger should turn ON.
5. If for any reason the charger draws more than 16.5 amps, short circuits or causes the power supply to run too hot, then the
power supply’s automatic protection circuits will activate and stop the operation of the power supply until the condition is resolved.
6. To turn the power supply OFF, press the side of the rocker switch marked with a circle “ O “.
NOTICE: All instructions, warranties, and other collateral documents are subject to change at the sole discretion
of Horizon Hobby, Inc. For up to date product literature, visit http://www.horizonhobby.com
