BL15 Ducted Fan Brushless Motor Instructions
Thank you for purchasing the E-flite BL15 DF Brushless Motor. This motor is an ideal choice for products
such as E-flite’s BAe Hawk 15 DF and other similar sized ducted fan airplanes when using the purpose-built
Delta-V 15 69mm EDF (EFLDF15). The motor will provide great performance in 68-70mm diameter fan
units requiring a 28mm inrunner motor.
BL15 DF Motor Features:
• Purpose-built for the Delta-V 15 69mm EDF (EFLDF15)
• Ideal for 68-70mm EDF units requiring a 28mm diameter inrunner motor
• Ideal for up to 750 input watts
• High-quality construction with ball bearings and hardened steel shaft
• 6-pole design
BL15 DF Specifications
Diameter:
28mm
(1.10
in)
Case Length: 40mm (1.56 in)
Weight: 106g (3.7 oz)
Shaft Diameter: 4mm (.16 in)
EFLM3015DF
Kv: 3600 (rpms per volt)
Io: 2.80A @ 10V (no load current)
Ri: .02 ohms (resistance)
Continuous
Current:
46A*
Max Burst Current: 55A*
Cells: 3S-4S Li-Po or 10-14 Ni-MH/Ni-Cd
Recommended Ducted Fan Unit: Delta-V 15 69mm EDF (EFLDF15)
Static Thrust: 1.7 lbs on 3S (11.1V) – using recommended Delta-V 15
2.8 lbs on 4S (14.8V) – using recommended Delta-V 15
RPM: 31,000 on 3S (11.1V) – using recommended Delta-V 15
40,000 on 4S (14.8V) – using recommended Delta-V 15
Brushless ESC: 50A – 60A
* Maximum Operating Temperature: 220 degrees Fahrenheit
* Adequate cooling is required for all motor operation at maximum current levels.
* Maximum Burst Current duration is 15 seconds. Adequate time between maximum burst intervals is
required for proper cooling and to avoid overheating the motor.
* Maximum Burst Current rating is for full high power and limited motor run flights. Lack of proper throttle
management may result in damage to the motor since excessive use of burst current may overheat the
motor.
Battery Choices:
EFLB32003S
3S 11.1V 3200mAh Li-Po, 13AWG
THP33003SXV
3S 11.1V 3300mAh Li-Po, 13AWG eXtreme V2 Series
THP26004SXV
4S 14.8V 2600mAh Li-Po, 13AWG eXtreme V2 Series
There are many Li-Po battery brands on the market with several choices for consumers. We recommend
either E-flite or Thunder Power batteries and list some possible choices for the BL15 DF Brushless Motor,
depending on the airplane application.
