2 E-flite Rhapsody 25e ARF Assembly Manual
Notice
All instructions, warranties and other collateral
documents are subject to change at the sole
discretion of Horizon Hobby, Inc. For up-to-date
product literature, visit http://www.horizonhobby.
com and click on the support tab for this product.
Meaning of Special Language
The following terms are used throughout the product
literature to indicate various levels of potential harm
when operating this product:
NOTICE: Procedures, which if not properly followed,
create a possibility of physical property damage
AND a little or no possibility of injury.
CAUTION: Procedures, which if not properly followed,
create the probability of physical property damage
AND a possibility of serious injury.
WARNING: Procedures, which if not properly followed,
create the probability of property damage, collateral
damage, and serious injury OR create a high
probability of superficial injury.
WARNING: Read the ENTIRE instruction manual
to become familiar with the features of the product
before operating. Failure to operate the product
correctly can result in damage to the product, personal
property and cause serious injury.
This is a sophisticated hobby product and NOT a toy.
It must be operated with caution and common sense
and requires some basic mechanical ability. Failure to
operate this Product in a safe and responsible manner
could result in injury or damage to the product or
other property. This product is not intended for use
by children without direct adult supervision. Do not
attempt disassembly, use with incompatible components
or augment product in any way without the approval
of Horizon Hobby, Inc. This manual contains
instructions for safety, operation and maintenance. It
is essential to read and follow all the instructions and
warnings in the manual, prior to assembly, setup or
use, in order to operate correctly and avoid damage
or serious injury.
Introduction
The Rhapsody 25e combines modern styling with
classic lines to give you a one-of-a-kind sport biplane
that’s a real standout. On the ramp, its striking
Ultracote ® trim scheme, along with the factory-painted
fiberglass cowl and wheel pants, will turn more than
a few heads. In the air, its crisp roll rates and smooth,
predictable flight characteristics will let you enjoy a
wide range of sport aerobatics without any surprises.
Best of all, you can have the Rhapsody 25e flying in
just an evening or two thanks to handy features like the
bolt-on tail and included wing jigs that make assembly
a breeze.
Important Information
Regarding Warranty Information
Please read our Warranty and Liability Limitations
section on Page 21 before building this product. If you
as the Purchaser or user are not prepared to accept the
liability associated with the use of this Product, you are
advised to return this Product immediately in new and
unused condition to the place of purchase.
Specifications
Wingspan: 47.0 in (1190mm)
Length: 39.0 in (990mm)
Wing Area: 530 sq in (34.0 sq dm)
Weight with Battery: 4.40–4.60 oz (1.90–2.10 kg)
Weight w/o Battery: 3.70–3.90 oz (1.60–1.80 kg)
Using the Manual
This manual is divided into sections to help make
assembly easier to understand, and to provide breaks
between each major section. In addition, check boxes
have been placed next to each step to keep track
of its completion. Steps with a single circle () are
performed once, while steps with two circles ( )
indicate the step will require repeating, such as for a
right or left wing panel, two servos, etc.
Remember to take your time and follow the directions.
Table of Contents
Notice ................................................................... 2
Meaning of Special Language ................................. 2
Introduction ........................................................... 2
Important Information Regarding
Warranty Information ........................................ 2
Specifications ......................................................... 2
Using the Manual ................................................... 2
Contents of Kit/Parts Layout .................................... 3
Covering Colors ..................................................... 3
Hardware/Accessory Sizes ..................................... 3
Recommended Radio Equipment ............................. 3
Power 25 Motor Setup ........................................... 3
Power 32 Motor Setup ........................................... 3
Required Tools and Adhesives ................................. 3
Optional Accessories .............................................. 3
Warnings .............................................................. 4
Rudder and Stabilizer Installation ............................ 4
Landing Gear Installation ........................................ 5
Motor, Speed Control and Cowling Installation ......... 7
Aileron Servo Installation ........................................ 9
Rudder and Elevator Servo Installation ................... 11
Bottom Wing and Receiver Installation ................... 13
Top Wing Installation ............................................ 14
Removing the Wing Panels ................................... 17
Motor Battery, Propeller and Pilot Installation ......... 17
Center of Gravity ................................................. 18
Control Throws..................................................... 19
Preflight ............................................................... 19
Flying Your Rhapsody 25e ARF ............................. 20
Range Test Your Radio .......................................... 20
Safety Do’s and Don’ts for Pilots ............................ 20
Daily Flight Checks ............................................... 20
Warranty and Repair Policy .................................. 21
Warranty Services ................................................ 21
Compliance Information for the European Union .... 22
2010 Official Academy of
Model Aeronautics Safety Code ....................... 22
