E-flite Ultimate 3D Profile ARF - Manual (Page 2)

3
Warning
An RC aircraft is not a toy! If misused, it can cause
serious bodily harm and damage to property. Fly
only in open areas, preferably at AMA (Academy of
Model Aeronautics) approved flying sites, following
all instructions included with your radio.
Additional Required Equipment
Recommended JR® Systems
Servos: JR 241 Sub-micro servo (4)
Receiver: JR R610M 6-channel micro FM Rx
Battery and Speed Control Requirements
Li-Po Battery: 7.4V 860–2100 2-Cell (stock motor)
11.1V 860–2100 3-Cell (brushless motor)
Speed Control: 20 Amp (EFLA105)
Additional Tools and Adhesives
Tools
Square 1/16" drill bit
Hobby knife Sewing needle
Ruler Pliers
Small Phillips screwdriver
Motor/Gearbox
370 size with 6.6:1 gearbox (included)
Propeller: (included)
20mm diameter w/gearbox brushless (optional)
Adhesives
Foam-safe CA
6-minute epoxy
Silicon glue
Other
Clear tape
T-pins
2
Table of Contents
Specifications ........................................................2
Warning ...............................................................3
Additional Required Equipment ...............................3
Additional Tools and Adhesives ...............................3
Contents of Kit/Parts Layout ....................................4
Complete parts listing .............................................5
Warranty Information .............................................6
Introduction ...........................................................7
Before Starting Assembly ........................................7
Using the Manual ..................................................7
Brushed vs. Brushless Motors ...................................8
Decal Installation ...................................................9
Stabilizer Installation ............................................10
Landing Gear Installation ......................................12
Rudder and Elevator Linkages ...............................15
Wing Installation .................................................19
Top Wing Installation (Ultimate) .............................21
Aileron Servo Installation ......................................22
Ultimate Aileron Connection Linkage ......................25
Gearbox Installation .............................................28
Final Assembly ....................................................30
Control Throws ....................................................31
Longitude Balance ...............................................32
Specifications
Tribute:
Wingspan: 37 in (940 mm)
Length: 37.5 in (952.5 mm)
Wing Area: 374.62 sq in (24.2 sq dm)
Weight w/o Battery: 9 oz (225.1g)
Ultimate:
Wingspan: 28 in (711 mm)
Length: 29.5 in (749 mm)
Wing Area: 384.7 sq in (24.8 sq dm)
Weight w/o Battery: 9 oz (225.1g)
Center of Gravity .................................................32
Setting up for 3D flight .........................................33
Flying .................................................................35
2004 Official AMA
National Model Aircraft Safety Code .....................38
