E-flite Ultimate 3D Profile ARF - Manual (Page 14)

15
Rudder and Elevator Linkages
Required Parts
Fuselage Control horn (2)
Pushrod guide (12) Pushrod wire (2)
Control horn backplate (2) Double-sided tape (2)
Micro pushrod keepers (2)
Micro control connectors (2)
Required Tools and Adhesives
Square Hobby knife
Ruler Foam safe CA
Pliers Servo (2)
❍ 1. Cut slots in the fuselage for the rudder and
elevator servo arms to pass through.
14
❍ 5. Press the tail skid into position on the bottom
of the fuselage. Remove the skid and apply
2–3 drops of foam-safe CA onto the skid and
press it into the holes.
