H. Load Footing File
Same as load heading, except for footer.
G., H. Brings up headers and footers that were pro-
grammed and saved at an earlier time. You may
recall the footer or header to program into you test
kit. The recalled or “Loaded” information will
overwrite current information.
I. Save Heading
J. Save Footing
I, J, Use this option when you have changed the header
or the footer and want to save the changes. You
can save each header and footer in a separate file.
You can then recall or “Load” the header or footer to
be programmed into your test kit.
K. Down Load Tests
Down loads from TK-DL to disc.
L. Print Tests
On screen prompts:
F2 OK, F4 scroll up, F6 scroll on,
Esc to cancel.
Lists date and Time tests
were recorded.
to select test to print
Note: The disc included with your test kit allows you
to change your header or footer. Therefore, the disc
should not be carried in the test kit case.
Watts TK-DL Software Instructions
The Watts TKDLC102 Software Disc is menu driven and will prompt you throughout the process of down loading your Watts
TK-DL test results to a personal computer. The following information has been provided to assist you in utilizing your Watts
TK-DL test kit.
TK DLC 102: Enter
READ WRITE TO TESTER: Enter
Connect TK-DL to computer and turn on
(on screen instructions)
A. Load Data from Tester
Reads Tester information in memory.
B. Display settings
Model = Watts TK-DL
Eprom Version
Serial #
Time/Date
Last Calibrated
Next Cal Due
Next Test #
C. Change Settings
Time/Date - day only
D. Display Heading and Footer
Displays heading and footer in TK-DL
memory printed on tape.
E. Change Heading and Footer
Allows heading and footer to be changed
by using computer keyboard.
F. Write Data to Tester (Saves information to the
Test Kit once you have changed the header or
the footer or anything in the “Change Settings”
option).
G. Load Heading File
It recalls a heading that was previously
saved. You can then load into the TK-DL
when you are connected to the computer.
After loading you must write data to tester
(Step F).
➝
➝
