AR60X Installation Manual
3 580­00517, rev B
2.4 Link Distance
Measurement of the link distance is important in estimating the link availability and calculating
expected Receive Signal Level (RSL). This measurement can be performed using the Latitude and
Longitude readings from a Global Positioning System (GPS) device, which is placed near the
proposed locations of the antennas, or using a range finder device.
The Minimum Link Distances are as follows:
· AR/GE/FE 60: 65 feet (20 meters)
· AR60X: 330 feet (100 meters)
To estimate maximum distances and availabilities for a given product and region, BridgeWave’s Path
Availability Calculator can be used. To obtain the latest version of BridgeWave’s Path Availability
Calculator, contact BridgeWave’s Customer Service or search the eService center knowledgebase
2.5 Antenna Location
The optimum location for the antennas must be determined. The ideal location should provide for ease
of erecting and mounting the antenna, as well as unimpeded Line­Of­Sight (LOS) to the other site.
The following factors should be taken into account:
· Type of mounting—fixed or roof­safe pole mounting
· Location where the fiber and DC power wiring will enter/exit the building
· Length of cable runs
· Grounding connection points
· Obstructions (LOS)
· Accessibility of mounting location
· Access to building after regular working hours
