AR60X Installation Manual
580­00517, rev B 8
3 Installation
3.1 General
It is recommended that installation personnel read this section in its entirety prior to installing the
BridgeWave System. During a particular phase of installation, the user may refer directly to the
applicable subsection.
The Installation section is comprised of seven subsections covering the procedures and guidelines for
installing the BridgeWave Radio System.
Subsections 3 through 3.4 contain information necessary to prepare for the equipment
installation.
Subsections 3.5 through 3.8 covers equipment installation procedures.
Subsections 3.9 and 3.10 contains information necessary for aligning the antennas.
3.2 Equipment Unpacking
The radio system equipment will arrive in two boxes—one box for the low band radio and one box for
the high band radio. Locate the correct box (low band or high band) before beginning installation by
checking the label on the outside of the box or on the radio itself. It is recommended that the shipping
cartons and packing materials be retained in the event that it is necessary to return any equipment.
Unpacked radios can be identified by the color of their labels
found on their front faces or inside the unit after removing the
plastic back weather cover. The blue color label indicates a high
band radio and the red color label indicates a low band radio. See
Figure 3­5 for further details.
