Commercial Gas Burner OEM Setup Guide
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Peerless TC
TC-04 CG15 Mod 581 / 1156 1.05 / 4.4 15.2S / 15.2 25 / 50 - 4.875"
TC-05 CG25 Mod 758 / 1506 0.7 / 2.95 25.2S / 25.2 21 / 43 - 4.875"
TC-06 CG25 Mod 899 / 1833 0.7 / 3.15 25.3S / 25.3 25 / 50 - 4.875"
TC-07 CG25 Mod 1051 / 2179 0.75 / 3.45 25.4S / 25.4 28 / 60 - 4.875"
TC-07 CG50 Low/High 1085 / 2182 0.85 / 3.5 50.1S / 50.1 20 / 35 - 4.875"
TC-07 CG50 Mod 890 / 2182 0.6 / 3.5 50.1S / 50.1 17 / 35 - 4.875"
TC-08 CG25 Mod 1201 / 2527 0.7 / 3.3 25.5S / 25.5 32 / 105 - 4.875"
TC-08 CG50 Mod 1047 / 2507 0.6 / 3.2 50.2S / 50.2 20 / 40 - 4.875"
TC-08 CG50 Low/High 1259 / 2507 0.8 / 3.2 50.2S / 50.2 23 / 40 - 4.875"
TC-09 CG50 Low/High 1420 / 2862 0.8 / 3.1 50.3S / 50.3 24 / 42 - 4.875"
TC-09 CG50 Mod 1235 / 2862 0.6 / 3.1 50.3S / 50.3 21 / 42 - 4.875"
TC-10 CG50 Low/High 1599 / 3222 0.9 / 3.8 50.3S / 50.3 26 / 65 - 4.875"
TC-10 CG50 Mod 1234 / 3222 0.6 / 3.8 50.3S / 50.3 21 / 65 - 4.875"
TC-11 CG50 Mod 1452 / 3521 0.55 / 3.3 50.4S / 50.4 23 / 52 - 4.875"
TC-11 CG50 Low/High 1683 / 3521 0.8 / 3.3 50.4S / 50.4 26 / 52 - 4.875"
TC-12 CG50 Mod 1707 / 3918 0.55 / 3.1 50.5S / 50.5 27 / 65 - 4.875"
TC-12 CG50 Low/High 1931 / 3918 0.8 / 3.1 50.5S / 50.5 29 / 65 - 4.875"
TC-13 CG50 Low/High 2108 / 4199 0.9 / 3.5 50.5S / 50.5 31 / 85 - 4.875"
TC-13 CG50 Mod 1712 / 4199 0.55 / 3.5 50.5S / 50.5 27 / 85 - 4.875"
TC-14 CG50 Low/High 2262 / 4538 1.0 / 4.0 50.5S / 50.5 32 / 95 - 4.875"
TC-14 CG50 Mod 1732 / 4538 0.55 / 4.0 50.5S / 50.5 27 / 95 - 4.875"
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Scotch Marine
100HP CG50 Mod 1700 / 4200 0.55 / 3.6 50.5S / 50.5 26 / 90 - 4.00"
20HP CG15 Mod 468 / 840 0.9 / 3.44 15.1S / 15.1 23 / 43 - 4.12"
30HP CG15 Mod 641 / 1260 0.9 / 3.86 15.3S / 15.3 24 / 80 - 4.12"
40HP CG25 Mod 774 / 1680 0.75 / 3.58 25.2S / 25.2 22 /48 - 4.12"
50HP CG25 Mod 1037 / 2100 0.75 / 3.3 25.4S / 25.4 28 / 63 - 4.12"
60HP CG50 Mod 1044 / 2520 0.55 / 3.32 50.2S / 50.2 21 / 41 - 4.00"
70HP CG50 Mod 1228 / 2940 0.55 / 3.2 50.3S / 50.3 22 / 46 - 4.00"
80HP CG50 Mod 1443 / 3360 0.55 / 3.26 50.4S / 50.4 23 / 48 - 4.00"
90HP CG50 Mod 1443 / 3780 0.55 / 3.88 50.4S / 50.4 23 / 80 - 4.00"
