Beckett CG25 - Manual (Page 4)

Commercial Gas Burner OEM Setup Guide
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Burnham MPC
MPC 4 CG10 Low Fire Start 500 1.0 / 1.8 10.3 / 10.3 - 6/0 4.25"
MPC 5 CG10 Low Fire Start 773 1.6 / 3.2 10.5S / 10.4 - 10/0 4.25"
MPC 6 CG15 Mod 540 / 995 1.15 / 3.15 15.2S / 15.2 26 / 45 - 4.25"
MPC 7 CG15 Mod 628 / 1216 1.1 / 3.6 15.3S / 15.3 29 / 60 - 4.25"
MPC 8 CG15 Mod 668 / 1438 1.1 / 3.6 25.1S / 25.1 16 / 45 - 4.25"
MPC 9 CG25 Mod 772 / 1660 0.8 / 3.57 25.2S / 25.2 22 / 48 - 4.25"
MPC10 CG25 Mod 878 / 1881 0.75 / 3.4 25.3S / 25.3 25 / 54 - 4.25"
MPC11 CG25 Mod 1052 / 2103 0.9 / 3.6 25.4S / 25.4 27 / 62 - 4.25"
MPC12 CG25 Mod 1048 / 2325 0.9 / 4.2 25.4S / 25.4 29 / 83 - 4.25"
MPC13 CG50 Mod 1048 / 2325 0.8 / 3.6 50.2S / 50.2 20 / 39 - 4.25"
MPC14 CG50 Mod 1247 / 2769 0.7 / 3.4 50.3S / 50.3 22 / 43 - 4.25"
MPC15 CG50 Mod 1216 / 2991 0.7 / 4.0 50.3S / 50.3 22 / 50 - 4.25"
MPC16 CG50 Mod 1214 / 3213 0.7 / 4.3 50.3S / 50.3 21 / 70 - 4.25"
MPC17 CG50 Mod 1471 / 3435 0.7 / 4.0 50.4S / 50.4 24 / 60 - 4.25"
MPC18 CG50 Mod 1389 / 3657 0.7 / 4.9 50.4S / 50.4 25 / 72 - 4.25"
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Burnham V11
V1104 CG10 Low Fire Start 843 1.0 / 3.3 10.6S / 10.6 - 10 / 0 4.00"
V1104 CG15 Mod 478 / 845 1.1 / 3.45 15.1S / 15.1 22 / 42 4.00"
V1105 CG10 Low Fire Start 1070 1.0 / 4.75 10.6S / 10.6 - 10 / 5 4.00"
V1105 CG15 Mod 554 / 1078 0.9 / 3.8 15.2S / 15.2 25 / 50 - 4.00"
V1106 CG15 Mod 757 / 1343 1.15 / 3.3 15.4S / 15.4 33 / 67 - 4.00"
V1106 CG25 Mod 670 / 1340 0.8 / 3.1 25.1S / 25.1 15 / 40 - 4.00"
V1107 CG25 Mod 782 / 1588 0.75 / 3.1 25.2S / 25.2 21 / 46 - 4.00"
V1108 CG25 Mod 896 / 1876 0.77 / 3.36 25.3S / 25.3 27 / 55 - 4.00"
V1109 CG25 Mod 1037 / 2136 0.78 / 3.32 25.4S / 25.4 28 / 62 - 4.00"
V1110 CG25 Mod 1200 / 2396 0.74 / 2.94 25.5S / 25.5 32 / 95 - 4.00"
V1111 CG50 Mod 1052 / 2710 0.55 / 3.55 50.2S / 50.2 20 / 42 - 4.00"
V1112 CG50 Mod 1238 / 2915 0.55 / 2.9 50.3S / 50.3 21 / 42 - 4.00"
V1113 CG50 Mod 1228 / 3103 0.53 / 3.4 50.3S / 50.3 21 / 50 - 4.00"
V1114 CG50 Mod 1443 / 3392 0.54 / 2.97 50.4S / 50.4 23 / 50 - 4.00"
V1115 CG50 Mod 1443 / 3680 0.54 / 3.4 50.4S / 50.4 23 / 70 - 4.00"
V1116 CG50 Mod 1700 / 3897 0.57 / 3.0 50.5S / 50.5 26 / 65 - 4.00"
V1117 CG50 Mod 1700 / 4186 0.57 / 3.44 50.5S / 50.5 26 / 75 - 4.00"
V1118 CG50 Mod 1700 / 4474 0.56 / 3.85 50.5S / 50.5 26 / 85 - 4.00"
V1119 CG50 Mod 1703 / 4713 0.57 / 4.15 50.5S / 50.5 26 / 95 - 4.00"
