Beckett CG25 - Manual (Page 11)

Commercial Gas Burner OEM Setup Guide
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Weil McLain 88 Series 2
488 CG10 Low Fire Start 986 1.5 / 4.5 10.6S / 10.6 - 10/4 4.00"
588 CG25 Mod 676 / 1357 0.8 / 3.5 25.1S / 25.1 16 / 41 - 4.00"
688 CG25 Mod 784 / 1729 0.8 / 3.7 25.2S / 25.2 22 / 53 - 4.00"
788 CG50 Mod 904 / 2017 0.6 / 3.1 50.1S / 50.1 19 / 32 - 4.00"
888 CG50 Mod 1030 / 2396 0.5 / 3.05 50.2S / 50.2 20 / 39 - 4.00"
988 CG50 Mod 1055 / 2666 0.6 / 3.75 50.2S / 50.2 20 / 43 - 4.00"
1088 CG50 Mod 1228 / 3089 0.55 / 3.65 50.3S / 50.3 21 / 48 - 4.00"
1188 CG50 Mod 1458 / 3403 0.6 / 3.6 50.4S / 50.4 23 / 53 - 4.00"
1288 CG50 Mod 1462 / 3762 0.6 / 4.15 50.4S / 50.4 23 / 75 - 4.00"
1388 CG50 Mod 1719 / 4171 0.65 / 4.0 50.5S / 50.5 26 / 70 - 4.00"
