Commercial Gas Burner OEM Setup Guide
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Burnham V9A
V903A CG10 Low Fire Start 442 1.1 / 2.5 10.1S / 10.1 - 10 / 1 4.125"
V904A CG10 Low Fire Start 618 1.1 / 2.6 10.4S / 10.4 - 5 / 2 4.125"
V905A CG10 Low Fire Start 811 1.2 / 3.3 10.5S / 10.5 - 7 / 1 4.125"
V906A CG10 Low Fire Start 1010 1.2 / 4.0 10.6S / 10.6 - 10 / 6 4.125"
V907A CG15 Mod 641 / 1192 0.9 / 3.6 15.3S / 15.3 28 / 64 - 4.125"
V908A CG15 Mod 736 / 1381 0.95 / 3.4 15.4S / 15.4 33 / 75 - 4.125"
V908A CG25 Mod 752 / 1378 0.9 / 3.2 25.1S / 21.1 16 / 41 - 4.125"
V909A CG25 Mod 774 / 1674 0.9 / 3.4 25.2S / 25.2 23 / 47 - 4.125"
V910A CG25 Mod 896 / 1905 0.76 / 3.44 25.3S / 25.3 26 / 52 - 4.125"
V911A CG25 Mod 1041 / 2108 0.8 / 3.2 25.4S / 25.4 28 / 62 - 4.125"
V912A CG50 Mod 1027 / 2360 0.55 / 2.6 50.2S / 50.2 20 / 38 - 4.125"
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Crown 24
03 CG10 Low Fire Start 442 1.1 / 2.5 10.1S / 10.1 - 10 / 1 4.125"
04 CG10 Low Fire Start 618 1.1 / 2.6 10.4S / 10.4 - 5 / 2 4.125"
05 CG10 Low Fire Start 811 1.2 / 3.3 10.5S / 10.5 - 7 / 1 4.125"
06 CG10 Low Fire Start 1010 1.2 / 4.0 10.6S / 10.6 - 10 / 6 4.125"
07 CG15 Mod 641 / 1192 0.9 / 3.6 15.3S / 15.3 28 / 64 - 4.125"
08 CG15 Mod 736 / 1381 0.95 / 3.4 15.4S / 15.4 33 / 75 - 4.125"
08 CG25 Mod 752 / 1378 0.9 / 3.2 25.1S / 25.1 16 / 41 - 4.125"
09 CG25 Mod 774 / 1674 0.9 / 3.4 25.2S / 25.2 23 / 47 - 4.125"
10 CG25 Mod 896 / 1905 0.76 / 3.44 25.3S / 25.3 26 / 52 - 4.125"
11 CG25 Mod 1041 / 2108 0.8 / 3.2 25.4S / 25.4 28 / 62 - 4.125"
12 CG50 Mod 1027 / 2360 0.55 / 2.6 50.2S / 50.2 20 / 38 - 4.125"
