Beckett CG25 - Manual (Page 3)

Commercial Gas Burner OEM Setup Guide
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Buderus G315
5 CG10 Low Fire Start 437 1.0 / 1.8 10.2S / 10.2 - 4.5 / 0 4.50"
6 CG10 Low Fire Start 551 1.0 / 2.1 10.3S / 10.3 - 6.5 / 0 4.50"
7 CG10 Low Fire Start 678 1.0 / 3.6 10.4S / 10.4 - 8 / 0 4.50"
8 CG10 Low Fire Start 800 1.0 / 3.9 10.5S / 10.5 - 10 / 0 4.50"
9 CG10 Low Fire Start 906 1.0 / 3.8 10.6S / 10.5 - 10 / 3 4.50"
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Buderus SB615
145 CG10 Low Fire Start 497 0.9 / 1.8 10.3S / 10.3 - 8 / 0 6.50"
185 CG10 Low Fire Start 644 0.9 / 1.7 10.4S / 10.4 - 8 / 0 7.00"
240 CG10 Low Fire Start 835 1.0 / 2.0 10.5S / 10.5 - 10 / 2 7.00"
240 CG15 Mod 468 / 835 1.2 / 3.9 15.1S / 15.1 22 / 46 - 7.00"
310 CG10 Low Fire Start 1080 1.2 / 2.4 10.6S / 10.6 - 10 / 8 7.00"
310 CG15 Mod 641 / 1080 1.2 / 3.4 15.3S / 15.3 28 / 60 - 7.00"
400 CG25 Mod 669 / 1393 0.95 / 4.1 25.1S / 25.1 15 / 45 - 7.00"
510 CG25 Mod 896 / 1776 1.0 / 4.1 25.3S / 25.3 27 / 58 - 7.00"
640 CG50 Low/High 1101 / 2214 0.95 / 4.1 50.1S / 50.1 21 / 35 - 7.00"
640 CG50 Mod 892 / 2214 0.6 / 4.1 50.1S / 50.1 18 / 35 - 7.00"
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Buderus SB735
1200 CG50 Mod 1719 / 4162 0.7 / 5.0 50.5S / 50.5 26 / 86 - 9.00"
790 CG50 Mod 1245 / 2802 0.65 / 3.9 50.3S / 50.3 21 / 48 9.00"
970 CG50 Mod 1443 / 3378 0.78 / 4.3 50.4S / 50.4 23 / 65 - 9.00"
