Commercial Gas Burner OEM Setup Guide
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Peerless LC/LCE
LC04 CG10 Low Fire Start 691 1.4 / 3.2 10.5S / 10.4 - 7.5 / 0 3.00"
LC05 CG15 Low/High 468 / 881 0.8 / 2.9 15.2S / 15.1 25 / 40 - 3.00"
LC05R CG15 Low/High 476 / 806 0.9 / 2.35 15.2S / 15.1 25 / 37 - 3.00"
LC06 CG15 Low/High 550 / 1086 0.9 / 3.9 15.2S / 15.2 25 / 52 - 3.00"
LC07 CG15 Low/High 641 / 1270 0.8 / 3.65 15.3S / 15.4 33 / 59 - 3.00"
LC07 CG25 Mod 659 / 1280 0.7 / 3.0 25.1S / 25.1 16 / 38 - 3.00"
LC08 CG25 Mod 669 / 1469 0.7 / 3.4 25.1S / 25.1 16 / 43 - 3.00"
LC09 CG25 Mod 774 / 1664 0.7 / 3.4 25.2S / 25.2 21 / 49 - 3.00"
LC10 CG25 Mod 896 / 1860 0.8 / 3.1 25.3S / 25.3 25 / 52 - 3.00"
LC11 CG25 Mod 1037 / 2059 0.7 / 3.1 25.4S / 25.4 28 / 60 - 3.00"
LC12 CG25 Mod 1184 / 2278 0.7 / 2.9 25.5S / 25.5 32 / 68 - 3.00"
LCE13 CG50 Mod 1060 / 2460 0.55 / 2.7 50.2S / 50.2 20 / 40 - 3.00"
LCE14 CG50 Mod 1044 / 2657 0.5 / 3.5 50.2S / 50.2 20 / 42 - 3.00"
LCE15 CG50 Mod 1228 / 2850 0.5 / 2.9 50.3S / 50.3 21 / 42 - 3.00"
LCE16 CG50 Mod 1228 / 3043 0.5 / 3.2 50.3S / 50.3 21 / 49 - 3.00"
LCE17 CG50 Mod 1228 / 3236 0.5 / 3.5 50.3S / 50.3 21 / 70 - 3.00"
LCE18 CG50 Mod 1439 / 3451 0.55 / 3.05 50.4S / 50.4 23 / 50 - 3.00"
LCE19 CG50 Mod 1443 / 3622 0.5 / 3.2 50.4S / 50.4 23 / 60 - 3.00"
LCE20 CG50 Mod 1443 / 3815 0.5 / 3.7 50.4S / 50.4 23 / 75 - 3.00"
LCE21 CG50 Mod 1700 / 4027 0.5 / 3.1 50.5S / 50.5 26 / 75 - 3.00"
LCE22 CG50 Mod 1700 / 4239 0.5 / 3.3 50.5S / 50.5 26 / 78 - 3.00"
LCE23 CG50 Low/High 2197 / 4450 0.75 / 3.8 50.5S /50.5 33 / 82 - 3.00"
LCE23 CG50 Mod 1707 / 4450 0.55 / 3.8 50.5S / 50.5 26 / 82 - 3.00"
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Peerless SC/SCT
SC05 CG10 Low Fire Start 444 1.0 / 3.0 10.1 / 10.1 - 10 / 2 2.50"
SC06 CG10 On/Off 491 2.0 10.3 / 10.3 - 5 / 0 2.50"
SC07 CG10 On/Off 569 2.7 10.3 / 10.3 - 8 / 0 2.50"
SC08 CG10 Low Fire Start 656 1.5 / 3.4 10.4S / 10.4 - 6.5 / 0 2.50"
SC09 CG10 Low Fire Start 741 2.0 / 4.2 10.4S / 10.4 - 8.5 / 0 2.50"
SC10 CG10 Low Fire Start 802 2.0 / 3.9 10.5S /10.5 - 10 / 3 2.50"
