Beckett CG25 - Manual (Page 10)

Commercial Gas Burner OEM Setup Guide
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Weil McLain 80
380 CG10 Low Fire Start 336 0.7 / 1.8 10.1S / 10.1 - 3 / 0 3.00"
480 CG10 Low Fire Start 491 0.8 / 1.45 10.3S / 10.3 - 6 / 0 3.00"
580 CG10 Low Fire Start 639 1.6 / 3.11 10.4S / 10.4 - 8 / 0 3.00"
680 CG10 Low Fire Start 787 1.7 / 3.3 10.5S / 10.5 - 8 / 1 3.00"
780 CG10 Low Fire Start 943 1.0 / 3.2 10.6S / 10.6 - 10 / 3 3.00"
780 CG15 Mod 461 / 945 1.0 / 4.2 15.1S / 15.1 22 / 50 - 4.00"
880 CG10 Low Fire Start 1067 1.0 / 4.1 10.6S / 10.6 - 10 / 4 4.00"
880 CG15 Mod 542 / 1072 0.9 / 3.5 15.2S / 15.2 25 / 47 - 4.00"
980 CG15 Mod 641 / 1230 0.95 / 3.49 15.3S / 15.3 28 / 65 - 4.00"
1080 CG15 Mod 742 / 1392 0.8 / 3.0 15.4S / 15.4 28 / 62 - 4.00"
1080 CG25 Mod 682 / 1378 0.75 / 3.0 25.1S / 25.1 15 / 42 - 4.00"
1180 CG25 Mod 774 / 1526 0.73 / 2.83 25.2S / 25.2 21 / 43 - 4.00"
1280 CG25 Mod 787 / 1670 0.75 / 3.1 25.2S / 25.2 21 / 48 - 4.00"
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Weil McLain 88
488 / 488R CG10 Low Fire Start 995 1.0 / 3.8 10.6S / 10.6 - 10 / 4 4.00"
488 / 488R CG15 Mod 550 / 991 0.9 / 3.2 15.2S / 15.2 25 / 45 - 4.00"
588 CG25 Mod 656 / 1382 0.75 / 3.1 25.1S / 25.1 17 / 40 - 4.00"
688 CG25 Mod 774 / 1703 0.76 / 3.62 25.2S / 25.2 21 / 51 - 4.00"
788 CG50 Mod 888 / 2053 0.55 / 2.5 50.1S / 50.1 17 / 32 - 4.00"
888 CG50 Mod 1040 / 2350 0.55 / 2.2 50.2S / 50.2 20 / 37 - 4.00"
988 CG50 Mod 1044 / 2713 0.54 / 3.77 50.2S / 50.2 20 / 42 - 4.00"
988R CG50 Mod 1044 / 2482 0.55 / 3.12 50.2S / 50.2 20 / 39 - 4.00"
1088 CG50 Mod 1228 / 3103 0.55 / 3.52 50.3S / 50.3 21 / 53 - 4.00"
1088R CG50 Mod 1228 / 2887 0.56 / 3.1 50.3S / 50.3 21 / 42 - 4.00"
1188 CG50 Mod 1443 / 3392 0.57 / 3.14 50.4S / 50.4 23 / 50 - 4.00"
1288 CG50 Mod 1443 / 3753 0.55 / 3.73 50.4S / 50.4 23 / 75 - 4.00"
1388 CG50 Mod 1700 / 4113 0.59 / 3.45 50.5S / 50.5 26 / 70 - 4.00"
1488 CG50 Mod 1762 / 4488 0.6 / 3.2 50.5S / 50.5 26 / 90 - 4.00"
