Banner U-GAGE QT50U DC Series—Analog - Manual (Page 8)

Wiring
Integral Cable Model Quick-Disconnect Model (5-pin
Mini-style)
Quick-Disconnect Model (5-pin
Euro-style)
−
4
5
1
3
2
10–30 V dc
Remote Teach
0–2 V dc
4–20 mA or
0–10 V dc
Shield
+
Shield
4
5
1
3
2
10–30 V dc
Remote Teach
0–2 V dc
4–20 mA or
0–10 V dc
+
−
4
5
1
3
2
10−30 V dc
Remote Teach
0–2 V dc
4–20 mA or
0–10 V dc
+
Shield
−
1 = brown
2 = white
3 = blue
4 = black
5 = gray
1 = brown
2 = white
3 = blue
4 = black
5 = yellow
1 = brown
2 = white
3 = blue
4 = black
5 = gray
Banner recommends connecting the shield wire to earth ground or dc common.
Dimensions
Cabled Models 5-pin Mini-style Models
5-pin Euro-style
Models
67.4 mm
[2.66”]
38.1 mm
[1.5”]
18 mm
[0.71”]
66 mm
[2.6”]
84.2 mm
[3.32”]
33 mm
[1.3”]
Temperature
Sensor Location
Internal thread 1/2” NPSM
External thread M30 x 1.5
37 mm
[1.46”]
4x 4.4 mm dia
[0.17” dia]
50.8 mm
[2”]
50.8 mm
[2”]
34.2 mm
[1.35”]
34.2 mm
[1.35”]
U-GAGE QT50ULB Series Sensors with Analog Output
8 www.bannerengineering.com - tel: 763-544-3164 P/N 70137 Rev. B
