Multi-beam, & 4-wire scanner blocks, Models excess gain sensing mode – Banner MULTI-BEAM Series User Manual
Page 7: Beam pattern, Opposed mode 7, Sbex & sbrx1, Sbev & sbrx1, Sbexd & sbrxd1, Sbed & sbrd1, Sbe & sbr1

SBEX & SBRX1
Range: 700 feet (200m)
Response: 10ms on/off
Repeatability: 0.7ms
Beam: infrared, 940nm
Effective beam: 1" dia.
SBEV & SBRX1
Range: 100 feet (30m)
Response: 10ms on/off
Repeatability: 0.1ms
Beam: visible red, 650nm
Effective beam: 1" dia.
SBEXD &
SBRXD1
Range: 30 feet (9m)
Response: 10ms on/off
Repeatability: 0.7ms
Beam: infrared, 880nm
Effective beam: .14" dia.
SBED & SBRD1
Range: 10 feet (3m)
Response: 1ms on/off
Repeatability: 0.03ms
Beam: infrared, 880nm
Effective beam: .14" dia.
SBE & SBR1
Range: 150 feet (45m)
Response: 1ms on/off
Repeatability: 0.03ms
Beam: infrared, 940nm
Effective beam: 1" dia.
SBE/SBR1: this opposed pair has the highest gain available at 1 ms response.
SBED/SBRD1: fast response and small effective beam; will detect objects as small as .14 inch in crossection
moving at up to 10 feet per second. Best choice for repeatability of position sensing.
SBEX/SBRX1: best choice for opposed sensing in extremely dirty environments. Use for outdoor applications
and all applications requiring opposed range of 100 feet or more. Also useable side-by-side for long-distance
mechanical convergent sensing. Alignment difficult beyond 400 feet.
SBEV/SBRX1: SBEV has visible red beam for easiest alignment and system monitoring.
SBEXD/SBRXD1: wide beam angle and high gain for the most forgiving emitter-receiver alignment.
10
1
DISTANCE
100
1000
.1 FT
1 FT
10 FT
100 FT
SBED &
SBRD1
E
X
C
E
S
S
G
A
I
N
I
10
1
DISTANCE
100
1000
1 FT
SBEX &
SBRX1
10 FT
100 FT
1000 FT
E
X
C
E
S
S
G
A
I
N
I
10
1
DISTANCE
100
1000
.1 FT
1 FT
10 FT
100 FT
SBEXD &
SBRXD1
E
X
C
E
S
S
G
A
I
N
I
10
1
DISTANCE
100
1000
1 FT
SBEV &
SBRX1
10 FT
100 FT
1000FT
E
X
C
E
S
S
G
A
I
N
I
2
0
0
I
N
C
H
E
S
OPPOSED DISTANCE--FEET
4
6
8
10
4
8
12
4
8
12
SBED/SBRD1
10
1
DISTANCE
100
1000
1 FT
SBE &
SBR1
10 FT
100 FT
1000FT
E
X
C
E
S
S
G
A
I
N
I
0
0
20
40
60
20
40
60
150
450
600
750
I
N
C
H
E
S
SBEX/SBRX1
OPPOSED DISTANCE--FEET
300
25
0
0
I
N
C
H
E
S
OPPOSED DISTANCE--FEET
50
75
100
150
5
10
15
5
10
15
SBEV/SBRX1
0
0
10
20
30
10
20
30
6
12
18
24
32
I
N
C
H
E
S
SBEXD/SBRXD1
OPPOSED DISTANCE--FEET
Models
Excess Gain
Sensing Mode
MULTI-BEAM
3- & 4-wire Scanner Blocks
30
0
0
I
N
C
H
E
S
OPPOSED DISTANCE--FEET
60
90
120
150
20
40
60
20
40
60
SBE/SBR1
OBJECT
OPPOSED Mode
7
Beam Pattern
