Euro-Style Quick-Disconnect Cables

4-Pin Threaded M12/Euro-Style Cordsets

Model

Length

Style

Dimensions

Pinout

MQDC-406

1.83 m (6 ft)

Straight

44 Typ.

ø 14.5

M12 x 1

1 = Brown
2 = White
3 = Blue
4 = Black

MQDC-415

4.57 m (15 ft)

MQDC-430

9.14 m (30 ft)

MQDC-450

15.2 m (50 ft)

MQDC-406RA

1.83 m (6 ft)

Right-Angle

32 Typ.

[1.26"]

30 Typ.

[1.18"]

ø 14.5 [0.57"]

M12 x 1

MQDC-415RA

4.57 m (15 ft)

MQDC-430RA

9.14 m (30 ft)

MQDC-450RA

15.2 m (50 ft)

Extension Cables

The following cables are available for extending the length of existing sensor cable. These are 30 m (100 ft) lengths of

MINI-BEAM cable, which may be spliced to the existing cable. Connectors, if used, must be customer-supplied.

Model

Type

Used With

EC312-100

4-conductor

MINI-BEAM dc receivers

EC312A-100

2-conductor

MINI-BEAM emitters
