• Compact, self-contained opposed mode modulated infrared sensor pairs for 10 to
30 V dc operation
• Standard sensor pairs have 3 m (10 ft) range; long range sensor pairs have 30 m
(100 ft) range
• Switch-selectable for light operate or dark operate; highly repeatable, 1
millisecond response
• Both sourcing and sinking outputs (150 mA maximum each)
• Receivers include Banner’s exclusive AID ™ alignment system, US patent number
4356393
• Rugged, epoxy-encapsulated construction: meets NEMA standards 1, 2, 3, 3S, 4,
4X, 6, 12, and 13, IEC IP67
• Physically and electrically interchangeable with 18 mm barrel-type photoelectrics
WARNING: Not To Be Used for Personnel Protection
Never use this device as a sensing device for personnel protection. Doing so could lead to
serious injury or death. This device does not include the self-checking redundant circuitry necessary
to allow its use in personnel safety applications. A sensor failure or malfunction can cause either an
energized or de-energized sensor output condition.
Models 1 2 Range Cable Excess Gain Beam Pattern
SM31E (Emitter)
3 m (10 ft)
2 m (6.5 ft)
1
10
100
.10 m
.33 ft
1.0 m
3.3 ft
10 m
33 ft
.01 m
.033 ft
Distance
1000
Excess Gain
SM31E & SM31R
Opposed Mode
3.0 m
10 ft
2.4 m
8 ft
1.8 m
6 ft
1.2 m
4 ft
0.6 m
2 ft
0
0
100 mm
200 mm
300 mm
100 mm
200 mm
300 mm
0
4.0 in
8.0 in
12.0 in
4.0 in
8.0 in
12.0 in
Distance
SM31E & SM31R
Opposed Mode
SM31R (Receiver)
SM31EQD (Emitter)
4-Pin Euro QD
SM31RQD (Receiver)
SM31EL (Emitter)
30 m (100
ft)
2 m (6.5 ft)
1
10
100
1.0 m
3.3 ft
10 m
33 ft
100 m
330 ft
0.1 m
0.33 ft
1000
Distance
SM31EL & SM31RL
Opposed Mode
Excess Gain
30 m
100ft 24 m
80 ft
18 m
60 ft
12 m
40 ft
6 m
20 ft
0
0
250 mm
500 mm
750 mm
250 mm
500 mm
750 mm
0
10.0 in
20.0 in
30.0 in
10.0 in
20.0 in
30.0 in
Distance
SM31EL & SM31RL
Opposed Mode
SM31RL (Receiver)
SM31ELQD (Emitter)
4-Pin Euro QD
SM31RLQD (Receiver)
1 To order the 9 m (30 ft) cable models, add the suffix “W/30” to the model number of any cabled sensor (e.g., SM31EL W/30). To
order the 150 mm (6 inch) long pigtail cable with attached QD connector models, add the suffix “QDP” to the model number of
any MINI-BEAM sensor (e.g., SM31ELQDP). Models with a QD connector require an accessory mating cable.
2 To order emitters and receivers with 0.3 millisecond on/off response, add the suffix “MHS” to the model numbers (e.g.,
SM31EMHS & SM31RMHS). This modification reduces sensing range (and excess gain).
MINI-BEAM SM31E/R Opposed Mode
Sensors
Original Document
03560 Rev. D
14 April 2014
