R55 Expert ™ Color Mark Sensors
10
P/N 59574 rev. B
Banner Engineering Corp. • Minneapolis, MN U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
Dimensions
SETUP
DO LO OFF Delay
Switch Point
+ DYNAMIC –
STATIC
21.0 mm
(0.83")
30.0 mm
(1.18") 30.4 mm
(1.20")
5.0 mm
(0.20")
3.0 mm (0.12")
15.0 mm
(0.59")
80.0 mm
(3.15")
43.0 mm
(1.69")
15.0 mm (0.59")
28.0 mm
(1.10")
M5 x 0.8 Thread
x 6.3 mm Deep (8 Holes),
max. torque 45 in./lbs.
25 mm
(1.0")
39.0 mm
(1.54")
28.0 mm
(1.10")
55.5 mm
(2.19")
15 mm
(0.59")
3 mm (0.12")
18.0 mm
(0.71")
bn
wh
bu
+
–
bk
pk
Load
0-10mA
Load
10-30V dc
Remote Input
gy
bn
wh
bu
+
–
bk
Load
Load
10-30V dc
Remote Input
gy
pk
0-10mA
Cabled Models Quick-Disconnect Models
Quick-Disconnect (QD) Cables
Style Model Length Dimensions Pinout
6-Pin
Euro-Style
Straight MQDC-0
MQDC-15
MQDC-30 2 m (6.5')
5 m (15')
9 m (30')
6-Pin
Euro-Style
Right-Angle MQDC-0RA
MQDC-15RA
MQDC-30RA 2 m (6.5')
5 m (15')
9 m (30')
38 mm max.
(1.5")
M12 x 1
ø 15 mm
(0.6")
38 mm max.
(1.5")
M12 x 1
ø 15 mm
(0.6")
44 mm max.
(1.7")
White Wire
Blue Wire
Pink Wire
Black Wire
Gray Wire
Brown Wire
Hookups
Euro-style QD Models
