Banner MAXI-BEAM Series - Manual (Page 6)

RSBF
Range: see excess gain
curves
Beam: infrared, 880nm
Response:
HP, 2W modes: 10ms
HS mode: 1ms
SP mode: 0.3ms
Repeatability:
HP, 2W= 3.3ms;
HS = 0.3ms;
SP = 0.1ms
NOTE: if the
retroreflective sensing
mode is used in
conjunction with the
HP or 2W program
mode, the GAIN control
must be reduced from
the factory setting in
order to avoid optical
feedback from the lens
assembly.
For information on the
complete line of Banner
glass fiber optics, see
Banner product catalog.
OPPOSED
MODE
RETRO
MODE
DIFFUSE
MODE
RSBFP
Range: see excess gain
curves
Beam: visible red, 650nm.
Response:
HS mode only, 1ms on/off
Repeatability:
HS = 0.3ms
Model RSBFP is a visible-light sensor head designed for use with plastic fiber
optics. It is compatible with all standard Banner plastic fiber optic assemblies (see
Banner product catalog). In order to function properly, the RSBFP must be
programmed for the "HS" response mode. The RSBFP is not for use with glass
fiber optics (instead use model RSBF or RSBFV).
10
1
.1 IN 1 IN 10 IN 100 IN
DISTANCE
RSBF
Opposed mode
SP
HS
100
1000
E
X
C
E
S
S
G
A
I
N
I
HP, 2W
IT23S fibers
10
1
DISTANCE
100
1000
.1 FT 1 FT 10 FT 100 FT
with
L9
lenses
with
L16F
lenses
Retroreflective
mode,
with BRT-3 reflector
and BT13S fibers
RSBF
E
X
C
E
S
S
G
A
I
N
I
HS
HS
10
1
.1 IN 1 IN 10 IN 100 IN
DISTANCE
RSBF
100
1000
SP
HS
HP, 2W
E
X
C
E
S
S
G
A
I
N
I
Diffuse mode
BT23S fibers
1
10
100
1000
.1 IN 1 IN 10 IN 100 IN
PIT46U
with L2
lenses
PIT26U,
no lens
DISTANCE
Opposed mode,
plastic fibers PIT46U,
no lenses
RSBFP
E
X
C
E
S
S
G
A
I
N
I
1
10
100
1000
.01 IN .1 IN 1 IN 10 IN
with
PBT46U
fiber
with
PBT26U
fiber
DISTANCE
RSBFP
(Range based on
90% reflectance
white test card)
Diffuse mode,
plastic fibers
E
X
C
E
S
S
G
A
I
N
I
1 2 3 0 4
0
.6
5
1.2
1.8
.6
1.2
1.8
PIT26U PIT46U
Opposed mode
I
N
C
H
E
S
OPPOSED DISTANCE--INCHES
RSBFP
.3 .6 0
0
.05
.10
.15
.05
.10
.15
1.2 1.5 .9
PBT26U PBT46U
Diffuse mode
I
N
C
H
E
S
DISTANCE TO 90% WHITE TEST CARD--INCHES
RSBFP
0
0
2
4
6
2
4
6
4 8 12 16 20
I
N
C
H
E
S
RSBF
DISTANCE TO REFLECTOR --FEE
Retroreflective mode with BT13S & BRT-3
HS with
L9 lenses
HS with
L16F lenses
0
0
.1
.2
.3
.1
.2
.3
1 2 3 4 5
I
N
C
H
E
S
RSBF
DISTANCE TO 90% WHITE TEST CARD--INCHES
Diffuse mode with BT23S fibers
SP
HS
HP, 2W
0
0
2
4
6
2
4
6
8 16 24 32 40
I
N
C
H
E
S
RSBF
OPPOSED DISTANCE --INCHE
Opposed mode with IT23S fibers
HP, 2W
HS
SP
The model RSBFP will
function only when
programmed for the "HS"
response mode.
The model RSBFP will
not operate with 2-wire
power blocks (models
R2PBA and R2PBB).
Sensing Mode Models Excess Gain
6
For information on the
complete line of Banner
plastic fiber optics, see
Banner product catalog.
OBJECT
OBJECT
RETROREFLECTOR
OBJECT
OBJECT
OBJECT
OPPOSED
MODE
DIFFUSE
MODE
FIBER OPTIC Mode
(glass fibers)
FIBER OPTIC Mode
(plastic fibers)
Beam Pattern
MAXI-BEAM
Sensor Heads
