U-GAGE ™ Analog Q45UR Remote Ultrasonic Sensors
P/N 59323 Rev. C 11
Banner Engineering Corp. • Minneapolis, MN U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
Mounting Brackets for M18C2.0 and S18C2.0 Sensors
SMB18S
46.0 mm
(1.81")
44.5 mm
(1.75")
36.0 mm
(1.42")
2.5 mm
(0.10")
25.4 mm
(1.00")
13.0 mm (0.50")
Nut Plate
Spacer
(If Required)
M5 x 0.8
x 60 mm
Screw (2)
6.4 m
(0.25
10.9 mm
(0.43")
SMB18A
• 11-gauge, stainless steel right-angle bracket
• Curved mounting slot for versatility and orientation
• 18 mm swivel, black PBT polyester bracket
• Stainless steel mounting hardware included
SMB18C
• 18 mm split clamp black PBT polyester bracket
• Stainless steel mounting hardware included
18.5 mm
(0.73")
25.4 mm
(1.00")
41 mm
(1.6")
46 mm
(1.8")
30 °
30 mm
(1.2")
R 24.2 mm
(0.95")
ø 4.6 mm*
(0.18")
4.6 mm*
(0.18")
* Use 4 mm (#8) screws
to mount bracket.
Drill screw holes
24.2 mm (0.95") apart.
7.6 mm
(0.30")
40.0 mm
(1.60")
42.4 mm
(1.67")
30.0 mm
(1.18")
2.5 mm
(0.10")
21.1 mm
(0.83")
Nut Plate
M5 x 0.8
x 60 mm
Screw (2)
13 mm
(0.5")
14.0 mm
(0.55")
D
