Q45VR3 Series
page 4
Banner Engineering Corp. • Minneapolis, U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
* 9 m (30') cables are available by adding suffix “W/30” to the model number of any cabled sensor (e.g., Q45VR3CV W/30)
A model with a QD connector requires a mating cable; see page 10.
Visible red, 680 nm
These sensors are ideal for reflective sensing of very small parts or profiles, and can accurately
sense the position of parts approaching from the side. Will ignore all but highly reflective objects
that are outside the sensing range.
Q45VR3 Series Convergent-Mode Models
190 mm
7.5 in
150 mm
6.0 in
113 mm
4.5 in
75 mm
3.0 in
38 mm
1.5 in
0
0
1.2 mm
2.5 mm
3.8 mm
1.2 mm
2.5 mm
3.8 mm
0
0.05 in
0.10 in
0.15 in
0.05 in
0.10 in
0.15 in
DISTANCE
Q45CV
Convergent Mode
Models Focus Cable*
Supply
Voltage
Output
Type
Excess Gain Beam Pattern
Q45VR3CV
Q45VR3CVQ
38 mm
(1.5")
Spot Size
at Focus:
1.3 mm
(0.05")
5-wire
2 m (6.5')
5-Pin
Mini-style QD
Universal
12 - 250V dc
or
24 - 250V ac SPDT
Electro-
mechanical
Relay
1
10
100
10 mm
.4 in
100 mm
4 in
1000 mm
40 in
1 mm
.04 in
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
Q45CV
Convergent Mode
190 mm
7.5 in
150 mm
6.0 in
113 mm
4.5 in
75 mm
3.0 in
38 mm
1.5 in
0
0
1.2 mm
2.5 mm
3.8 mm
1.2 mm
2.5 mm
3.8 mm
0
0.05 in
0.10 in
0.15 in
0.05 in
0.10 in
0.15 in
DISTANCE
Q45CV4
Convergent Mode
Q45VR3CV4
Q45VR3CV4Q
100 mm
(4")
Spot Size
at Focus:
1.5 mm
(0.06")
5-wire
2 m (6.5')
5-Pin
Mini-style QD
Universal
12 - 250V dc
or
24 - 250V ac SPDT
Electro-
mechanical
Relay
1
10
100
10 mm
.4 in
100 mm
4 in
1000 mm
40 in
1 mm
.04 in
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
Q45CV4
Convergent Mode
Performance based on 90% reflectance white test card
