5.2 Large maintenance
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
32 ￭￭￭￭￭￭￭￭
6.1246.120 Multi-Mode-Electrode pro
1 2 3
4
Figure 9 MME pro – Removing the capillary
1 Placing the MME pro into the electrode stand
￭ Place the electrode stand into the drip pan.
￭ Place the MME pro into the electrode stand.
The capillary retaining screw is pointing upwards.
2 Removing the capillary retaining screw
Loosen the capillary retaining screw and remove it.
3 Removing the capillary
Pull capillary and the seal out of the MME pro.
4 Removing the seal
Pull the capillary out of the seal.
The seal can be reused if it is undamaged.
