3 Installation
850 Professional IC – Anion – MCS – LP Gradient
￭￭￭￭￭￭￭￭ 19
3 Gradient mixing coil 6.2758.020 4 Column inlet capillary
Connected to the injection valve and threa-
ded into the capillary recesses of the column
thermostat.
5 Connection capillary
Capillary of the MSM labeled with Eluent. 6 Connection capillary
Capillary of the MSM labeled with Detector.
7 Detector inlet capillary 8 Sample aspirating capillary 6.1803.040
Connected to the injection valve. The other
end can be connected either to the sample
degasser or guided directly out of the instru-
ment.
9 PTFE connection capillary
Section of the 6.1803.040 PTFE capillary.
Connects the sample degasser with the
Sample Processor (required only if the sam-
ple degasser is used) 10 Regeneration solution aspirating capil-
lary 6.1803.020
Connection to the regeneration solution
bottle.
11 Pump tubing 6.1826.320
Pump tubing with yellow-orange stoppers
for conveying the regeneration solution.
12 Connection capillary for the regenera-
tion solution
Capillary of the MSM labeled with H2SO4.
13 Regeneration solution outlet capillary
Capillary of the MSM labeled with Waste.
14 Rinsing solution aspirating capillary
6.1803.020
Connection to the regeneration solution
bottle.
15 Pump tubing 6.1826.320
Pump tubing with yellow-orange stoppers
for conveying the rinsing solution.
16 Connection capillary for the rinsing
solution
Capillary of the MSM labeled with H20.
17 Rinsing solution outlet capillary
Capillary of the MSM labeled with Waste.
18 Air aspirating capillary
For aspirating CO
2
-low air from the car-
tridges of the MCS.
19 PEEK pressure screws, short
6.2744.070
20 PEEK pressure screws, long
6.2744.090
21 Tubing olive 6.2744.030 22 Pump tubing connection with safety
device 6.2744.180
You will find detailed descriptions of the individual installation steps in the
following chapters.
