3.15 Mounting the base plate
■■■■■■■■■■■■■■■■■■■■■■
40
■■■■■■■■
815 Robotic USB Sample Processor XL
Switch the barcode reader to programming mode and make the following
settings:
1
■
Select the keyboard layout for the desired country (USA, Ger-
many, France, Spain, Switzerland (German)). This setting must
match the setting in the control software.
■
Make sure that the Ctrl characters (ASCII 00 to 31) are allowed to
be sent.
■
Adjust the settings so that the ASCII character 02 (STX or Ctrl B) is
sent as the first character as "Preamble" or "Prefix Code".
■
Adjust the settings so that the ASCII character 04 (EOT or Ctrl D) is
sent as the last character as "Postamble" or "Record Suffix" or
"Postfix Code".
■
Exit programming mode.
3.15
Mounting the base plate
If it is needed by an application that a determination is not carried out on
the sample rack but in an external measuring cell, a stand plate can be
mounted. It can be placed on the left or on the right of a tower of the
815 Robotic USB Sample Processor XL. Any accessories parts can be
placed on the support rod of the stand plate.
