Part List
Locate the part that you wish to replace in the following figures, and then order the package that comes with the
specified part. The numbering of the part is defined as follow:
S1020101CCW
Package No.
01-Frame Arm
；02-Center Frame；
03-Landing Skid
S1000
Package Part No.
CW as clockwise
；CCW as counter clock
wise
；B as Black；
R as Red
；
G as Green
Frame Arm
S1012101B/
S1012201R
M3 12. 3
×
S1012301R/
01
S10124
G
S1010801
S1012501CCW/
S1012502CW
M3×12.3
S1012503
S1010401CCWB/
S1010501CCWR/
S1010601CWB/
S1010701CWR
S1012901/
S1013001/
S1013101/
S1013201
S1011001
S1012102B/
S1012202R
S1012302/
S1012402
M3 10. 3
×
S1010402/
S1010502/
S1010602/
S1010702
Package No.
Name
Part No.
4
S1000-Premium Frame Arm CCW - Black
S1010401CCWB
，S1010402，M3x12.3
5
S1000-Premium Frame Arm CCW - Red
S1010501CCWR
，S1010502，M3x12.3
6
S1000-Premium Frame Arm CW - Black
S1010601CWB
，S1010602，M3x12.3
7
S1000-Premium Frame Arm CW – Red
S1010701CWR
，S1010702，M3x12.3
8
S1000-Premium Motor Damping Unit
S1010801
，M3x10.3
10
S1000-Premium Motor Mount Carbon
Board
S1011001
，M3x10.3
21
S1000-Premium 4114 Motor with black Prop
cover
S1012101B
，S1012102B，M3x4.5
22
S1000-Premium 4114 Motor with red Prop
cover
S1012201R
，S1012202R，M3x4.5
23
S1000-Premium ESC with Red LED
S1012301R
，S1012302，M3x12.3
