DIMENSIONAL DRAWINGS

UNIT

F

in./mm

G

in./mm

CENTER OF GRAVITY in./mm

X

Y

Z

588A018040

16

9

16

/420.7

18

15

16

/481.0

25.07/637

20.59/523

10.85/276

588A024040

27.07/688

23.35/593

588A024060

26.98/685

23.27/591

588A030040

26.71/678

23.46/596

588A030060/080

27.15/689

22.36/568

588A036060/080

27.50/698

22.48/571

588A036100/120

27.40/696

22.44/570

588A042060/080

20

9

16

/522.3

22

15

16

/582.6

27.01/686

22.44/570

12.65/321

588A042100/120

26.94/684

22.44/570

LEGEND

CG

Center of Gravity

COND

Condenser

LV

Low Voltage

MAT’L

Material

NEC

National Electrical Code

REQ’D

Required

NOTES:
1. Clearances must be maintained to prevent recirculation of air from outdoor-fan

discharge.

2. Adequate clearance around air openings into combustion chamber must be

provided.

REQ’D CLEARANCES FOR SERVICING. in. (mm)

Duct panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0
Unit top . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 (914)
Side opposite ducts . . . . . . . . . . . . . . . . . . . . . . . . . 36 (914)
Compressor access . . . . . . . . . . . . . . . . . . . . . . . . . 36 (914)
(Except for NEC requirements)

REQ’D CLEARANCES TO COMBUSTIBLE MAT’L. in. (mm)

Maximum extension of overhangs . . . . . . . . . . . . . . . . . 48 (1219)
Unit top . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 (356)
Duct side of unit

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 (51)

Side opposite ducts . . . . . . . . . . . . . . . . . . . . . . . . . 14 (356)
Bottom of unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0
Flue panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 (914)

NEC REQ’D CLEARANCES. in. (mm)

Between units, control box side . . . . . . . . . . . . . . . . . . 42 (1067)
Unit and ungrounded surfaces, control box side . . . . . . . . . . 36 (914)
Unit and block or concrete walls and other

grounded surfaces, control box side . . . . . . . . . . . . . . . 42 (1067)

UNIT

ELECTRICAL

CHARACTERISTICS

UNIT WEIGHT

CORNER WEIGHT

(lb/kg)

UNIT HEIGHT

(in./mm)

lb

kg

A

B

C

D

E

588A018040

208/230-1-60

272

123

81/37

62/28

76/35

53/24

24.1/613

588A024040

208/230-1-60

303

138

97/44

43/20

123/56

40/18

24.1/613

588A024060

208/230-1-60

315

143

100/45

46/21

126/57

43/20

24.1/613

588A030040

208/230-1-60, 208/230-3-60

320

145

100/45

47/21

126/57

47/21

24.1/613

588A030060/080

208/230-1-60, 208/230-3-60

332

149

103/46

50/22

129/58

50/23

24.1/613

588A036060/080

208/230-1-60, 208/230-3-60, 460-3-60

336

153

86/39

76/35

111/50

63/29

24.1/613

588A036100/120

208/230-1-60, 208/230-3-60, 460-3-60

348

158

89/40

79/36

114/52

66/30

24.1/613

588A042060/080

208/230-1-60, 208/230-3-60, 460-3-60

375

170

95/43

86/39

119/54

75/34

28.1/714

588A042100/120

208/230-1-60, 208/230-3-60, 460-3-60

387

176

98/45

89/40

122/55

78/35

28.1/714

Unit 588A018-042 Without Base Rail

5
