Gauge Pod Assembly Diagrams

GT/WatchDog

When assembling, consider the following:

• Will the custom mount be painted? If so, paint the

mount BEFORE assembly.

IMPORTANT: A gauge pod adapter (sold separately, part

#30420) is required to mount a GT or WatchDog unit with a

custom pod mount.

GT/WatchDog™ Head Unit

Custom Pod Adaptar

(sold separately)

Custom Gauge Pod

GT Gauge Pod Assembly Diagram

(To OBDII Adapter Plug)

Main Harness

Main Harness Plug
