Boomba Racing Fiesta ST Transmission Cable Bracket Bushings - Manual

FORD FIESTA ST
TRANSMISSION BUSHINGS
1 Remove plastic vacuum hose from rubber
adaptor on the top of valve cover (leave
rubber adaptor in place). 1 Disconnect the MAF sensor. 2 Remove the air filter cover. 3 Remove the air filter. 4 Remove the vent line.
5 Loosen the air pipe clamp and remove the
air pipe. 6 Snap off the air supply duct from the latch. 7 Remove the air box. 8 Disconnect the battery terminals. Remove
the battery holder and remove the battery.
9 Remove the ECU cover.
10
Disconnect the ECU connectors.
11
Remove the battery tray with the ECU
attached.
12
Pry off the shifter cables from the shifter
arms with the flat head screw drivers.
MATERIALS REQUIRED
None
TOOLS REQUIRED
M7 socket wrench
M12 box wrench
M10 socket wrench
M12 socket wrench
T25 Torx bit
Large flat screw drivers
