Boomba Racing ST Focus Transmission Cable Bracket Bushings User Manual
Ford focus st transmission bushings

FORD FOCUS ST
TRANSMISSION BUSHINGS
1
Remove plastic vacuum hose from rubber
adaptor on the top of valve cover (leave
rubber adaptor in place).
1
Remove the MAF sensor connector.
2
Remove the air box cover.
3
Open the air duct brace.
4
Remove the battery cover.
5
Loosen up the hose clamps.
6
Remove the air box.
Remove battery tray.
7
Snap off the shifter cable connector.
8
Remove the shifter cables.
9
Remove the transmission shifter bracket.
10
Remove the metal sleeves and grommets
from the bracket.
11
Prepare Boomba Racing transmission
bushings.
MATERIALS REQUIRED
None
TOOLS REQUIRED
M8 socket wrench
M12 box wrench
Large flat screw driver
M7 socket wrench
M10 box wrench
12
The longer bolt holds the clutch line
bracket.
